HLA Attachments - 66" Regular Duty Standard Skid Steer Bucket - Universal Skid Steer Bucket [LA-SB66BO500]

HLA Attachments SB66-BO500 66-Inch Regular-Duty Standard Skid-Steer Bucket is a versatile material bucket designed for loaders and skid steers using a universal skid-steer-style quick-attach carrier. Combining a 66-inch inside width with a 15.0-cubic-foot struck capacity and 19.0-cubic-foot SAE heaped capacity, it provides practical carrying volume for routine loading, moving, filling, and cleanout work. Regular-duty construction, reinforced structural areas, and a substantial bevelled cutting edge make this bucket a dependable choice for everyday material-handling applications.

Durable Regular-Duty Construction

The SB66 bucket is manufactured with 3/16-inch bucket material and 1/4-inch end plates. Its reinforced top lip, round back, and reinforced end plates add strength where it is needed while supporting easy filling and cleanout. Tapered, self-cleaning end plates are designed to reduce material buildup, helping the bucket empty more cleanly during repeated loading cycles.

A 3/4 x 4-inch bevelled cutting edge provides a robust leading edge for engaging material. The bucket is also drilled to accept a standard bolt-on cutting edge, allowing compatible edge equipment to be fitted when required. Its flat top serves as a convenient level indicator, helping the operator judge bucket position during operation.

Practical Capacity and Dimensions

With a 66-inch inside width and an approximate 68-inch outside width, this HLA bucket offers useful coverage while maintaining a manageable overall size. The 28-inch depth and 26-inch height contribute to its 15.0-cubic-foot struck capacity and 19.0-cubic-foot SAE heaped capacity. Approximate bucket weight is 480 pounds.

The rounded, reinforced back is shaped to promote easy filling and material release. Together with the tapered end plates, this design supports efficient bucket loading and reduces material retention during cleanout.

Key Features

• Regular-duty standard skid-steer material bucket
• 66-inch inside bucket width
• Approximately 68-inch outside width
• 15.0-cubic-foot struck capacity
• 19.0-cubic-foot SAE heaped capacity
• 3/16-inch bucket material
• 1/4-inch end plates
• 3/4 x 4-inch bevelled cutting edge
• Drilled for a standard bolt-on cutting edge
• Reinforced top lip for added strength
• Reinforced round back and end plates
• Tapered, self-cleaning end plates designed to reduce material buildup
• Flat bucket top acts as a level indicator
• BO500 universal skid-steer quick-attach mounting
• Approximate weight of 480 pounds

Compatibility

The SB66-BO500 is configured with HLA mounting code BO500 and is compatible with loaders and skid steers equipped with a universal skid-steer-style quick-attach carrier. Confirm that the carrier interface and equipment capacity are suitable for the bucket and its intended load before installation and operation.

Specifications
