HLA Attachments - 60" Wide Rubber Feed Alley Scraper - Livestock and Farm Scraper [LA-RFH60BO500]

HLA Attachments RFH60-BO500 60-Inch Rubber Feed Alley Scraper is a hydraulic power-angle livestock and farm scraper designed for efficient cleaning of feed alleys. Its 60-inch-wide, 24-inch-high rubber blade is easy on concrete and tiled-floor mangers, making it well suited to routine cleanup where protecting the underlying surface is important. Hydraulic angling allows the blade to move up to 45 degrees in either direction, helping operators direct material to the left or right without manually repositioning the attachment.

Efficient Feed Alley Cleaning

The RFH60-BO500 combines a practical 60-inch working width with loader-mounted operation. The rubber scraper provides broad contact across the floor while remaining gentle on common manger surfaces. This makes it a useful attachment for maintaining livestock areas and clearing feed alleys.

A 24-inch blade height provides a substantial scraping surface, while the hydraulic power-angle function improves control over the direction in which material is moved. The blade can be angled as far as 45 degrees to either side, allowing the operator to adapt the scraper position to the layout of the alley and the required cleaning direction.

BO500 Quick-Attach Mount

This model is configured with HLA Attachments’ BO500 universal skid-steer-style loader mount. It is intended for loaders equipped with a compatible universal skid-steer-style quick-attach carrier. The mount configuration allows the scraper to be connected to a suitable loader for powered operation.

The attachment has an approximate weight of 495 lb. Loader capacity and attachment-carrier compatibility should be confirmed before use.

Key Features

• 60-inch-wide rubber feed alley scraper
• 24-inch-high blade
• Rubber scraper is easy on concrete and tiled-floor mangers
• Hydraulic power-angle adjustment
• Angles up to 45 degrees in either direction
• BO500 universal skid-steer-style loader mount
• Approximate attachment weight of 495 lb
• Designed for cleaning livestock feed alleys

Hydraulic Requirements

Loader auxiliary hydraulics are required to operate the power-angle function. Hydraulic flow and pressure requirements are not specified by the manufacturer. Confirm that the loader has suitable auxiliary hydraulic connections before installation.

Compatibility

The RFH60-BO500 is compatible with loaders equipped with a universal skid-steer-style quick-attach carrier. This product is specifically the BO500 mount variant; compatibility should be verified against the loader’s carrier, operating capacity, and hydraulic connection arrangement.

Optional Accessories

An optional HK90 90-inch hose kit with flat-faced couplers is available for hydraulic connection. An optional SHMK spring hose mount kit is also available. These accessories are optional and are not identified as standard equipment.

Specifications
