KIOTI TL750 Compact Track Loader Enclosed Cab

SKU TL750U-LQ
$104,08246
$104,08246

Add your machine and attachments to the Cart to begin to build and price your package!


When you're ready to take the next step, please reach out to us for a quote.

*Pricing shown at MSRP and may not include available Timberstar Tractor or Manufacturer discounts.
*Finance rates, payment calculations, whether or not you need a down payment, all available through our sales staff.
*Pricing may not include freight, assembly, finance, delivery, or pdi fees.
*Manufacturer pricing subject to change without notice.
*Manufacturer sales promotions valid unitl the end of the month they were issued in.
*Price match available for many brands we carry.

Description



KIOTI TL750 Track Skid Steer – With Heated & Cooled Cab

*we often have deep discounts on construction equipment, it's well worth your time to reach out for a quote.

Power, precision, and comfort — the KIOTI TL750 Track Skid Steer is engineered to handle the toughest jobs with ease, no matter the season. Built for performance and designed around operator comfort, the TL750 combines rugged reliability with advanced features that set a new standard in the compact equipment industry.

Unmatched Performance

At the heart of the TL750 is a powerful KIOTI diesel engine delivering the torque and responsiveness you need for demanding applications. Its durable rubber track system provides superior traction and stability on all terrain — from mud and gravel to snow and ice — making it a true year-round workhorse.

Premium Operator Comfort

Step inside the heated and cooled cab, and you’ll find a workspace built for productivity and comfort. The pressurized, climate-controlled cab keeps you warm in winter and cool in summer, while low noise levels and ergonomic controls reduce fatigue during long days on the job.

Built to Work Hard

  • Robust Lift Capacity: Handle heavy loads with confidence thanks to a strong vertical lift path and impressive rated operating capacity.

  • Advanced Hydraulics: Smooth, responsive power for attachments like buckets, augers, grapples, and more.

  • Easy Maintenance: Thoughtful design makes daily checks and servicing simple and quick.

  • LED Work Lights: Exceptional visibility for early mornings or late nights on the job site.

Key Specifications

  • Model: KIOTI TL750 Track Skid Steer

  • Engine: KIOTI Diesel – High-torque, fuel-efficient performance

  • Cab: Fully enclosed, pressurized, heated & cooled

  • Lift Path: Vertical

  • Track Type: Heavy-duty rubber tracks

  • Ideal For: Construction, landscaping, agriculture, snow removal, and property maintenance

Experience the KIOTI Difference.
The KIOTI TL750 Track Skid Steer is built for operators who demand power, control, and comfort in every season. Whether you’re lifting, grading, or clearing snow, the TL750 delivers the performance and dependability you can count on — day after day, job after job.





Specs


Engine
Engine Model 4HTI4
Engine Manufacturer KIOTI
Engine Power 73.60 hp (54.90 kW)
Engine Displacement 148.60 cu. in. (2,435 cc)
RPM 2,400 rpm
Fuel Type Diesel
Aspiration Natural
Fuel Capacity 26.40 gal (100 L)
Oil Capacity 2.40 gal (9 L)
Coolant Capacity 1.10 gal (4.20 L)
Radiator Coolant Capacity 10.40 gal (2.70 L)



Hydraulics
Lift Arm Path Vertical
Lift Control ISO Pilot
Tank Capacity 10 gal (38 L)
Pressure 3,335 psi (230 bar)
Pump Capacity 21.90 gpm (82.90 lpm)
Hydraulics Power 41.80 hp (31.10 kW)

Operating Specs
Tipping Load 5,380 lb (2,440 kg)
Rated Operating Capacity (50% of Tip Load) 2,690 lb (1,220 kg)
Rated Operating Capacity (35% of Tip Load) 1,883 lb (854 kg)
Breakout Force, Tilt (Bucket) 5,512 lb (2,500 kg)
Breakout Force, Lift 5,016 lb (2,275 kg)
Traction Force 6,347 lb (2,879 kg)
Travel Speed Forward Speeds 2
Travel Speed Reverse Speeds 2
Travel Speed Min Speed 7.15 mph (11.50 km/h)
Travel Speed Max Speed 12.05 mph (19.40 km/h)
Chain Box Capacity 3.40 gal (13 L)

Dimensions
Wheelbase 47.20 in (1,200 mm)
Length without Bucket 116.50 in (2,960 mm)
Length with Bucket 144.70 in (3,675 mm)
Height with Cab 81.20 in (2,063 mm)
Height with Cab & Beacon 85.10 in (2,161 mm)
Height Max 160.20 in (4,068 mm)
Hinge Pin Height at Max Lift 126.60 in (3,215 mm)
Hinge Pin Height at Max Carry 8.30 in (212 mm)
Reach at Max Lift and Dump 37.40 in (949 mm)
Clearance at Max Lift and Dump 97.40 in (2,473 mm)
Ground Clearance 7.70 in (195 mm)
Departure Angle 25 °
Bumper Overhang Behind Rear Axle 44.40 in (1,127 mm)
Dump Angle Max 42 °
Body Width Above Tires 71.70 in (1,820 mm)
Turning Radius Center to Rear 70.40 in (1,788 mm)
Turning Radius Center to Coupler 60.90 in (1,548 mm)
Turning Radius Center to Bucket 85 in (2,158 mm)
Rack Back Angle at Max Height 88 °
Bucket Pin Reach at Max Lift 16.30 in (414 mm)
Width with Bucket 74.40 in (1,890 mm)
Rack Back Angle at Ground Level 29 °
Front Tread 59.60 in (1,513 mm)
Rear Tread 59.60 in (1,513 mm)
Operating weight with operator 8,633 lb (3,916 kg)
Operating weight without operator 8,468 lb (3,841 kg)
