Vermeer TM210 14-Disc Trailed Mower – 1000 RPM, Floats, 2 Remotes [TM2917401]

The Vermeer TM210 14-Disc Trailed Mower – 1000 RPM, Floats, 2 Remotes [TM2917401] is a Vermeer trailed disc mower listed under product code TM2101220. The available manufacturer specifications identify the corresponding machine as the Vermeer TM1410 Trailed Mower, a 14-disc mower designed for efficient hay and forage cutting. It combines a Q3® cutter bar, hydraulic suspension, hydraulic pitch control and a 27.1 ft (8.3 m) working width to support productive mowing across broad fields. With a 1,000 rpm PTO drive, 105 hp recommended PTO power and two double-acting hydraulic circuits, this mower is suited to tractors equipped for the specified PTO, hydraulic and hitch requirements.

Product Features

The mower’s 14-disc cutting system provides a 20.8 ft (6.3 m) cutting width, while the stated working width extends to 27.1 ft (8.3 m). The Q3® cutter bar uses 23 in (58.4 cm) discs rotating at 2,690 rpm, with 28 blades delivering the cutting action. Cut height can be adjusted from 1–3 in (2.5–7.6 cm), allowing the machine to be configured for different mowing conditions.

Hydraulic suspension helps support the mower during operation, and hydraulic pitch control allows adjustment of the cutting angle. Flotation tires are specified as 480/45 × 17, with a 9.8 ft (3.0 m) transport width when fitted; the standard transport width is 9.1 ft (2.8 m). Quick-Clip® blade retention and Quick-Change™ shear ring systems are specified as standard, helping simplify blade and shear-ring servicing. Standard highway lights support road transport, while an optional swathwheel is available for swath formation.

Key Features

• 14-disc trailed disc mower configuration
• Q3® cutter bar
• 20.8 ft (6.3 m) cutting width
• 27.1 ft (8.3 m) working width
• 1,000 rpm PTO drive
• Hydraulic suspension
• Hydraulic pitch control
• 1–3 in (2.5–7.6 cm) cut-height range
• 23 in (58.4 cm) disc diameter and 2,690 rpm disc speed
• 28 blades
• Quick-Clip® blade retention system
• Quick-Change™ shear ring
• Driveline friction disc clutch for torque protection
• 480/45 × 17 flotation tires
• Standard highway lights
• Optional swathwheel
• Standard modular independent skid shoes

Specifications

Tractor Requirements and Compatibility

This mower requires a tractor with a 1,000 rpm PTO and approximately 105 PTO hp recommended. The tractor must have a Category II or III N 2-point quick hitch with swivel gearbox and two double-acting hydraulic circuits. Hydraulic requirements are 1,850 psi (127.6 bar) and 6 gpm (22.7 L/min).
