Vermeer TM1210 12-Disc Trailed Mower – 17.7 ft Cutting Width, 1000 RPM, Floats, 2 Remotes [TM1815661]

The Vermeer TM1210 Trailed Disc Mower is a wide-cutting, 12-disc mower designed for efficient hay and forage cutting across large fields. Its 17.7 ft (5.4 m) cutting width, Q3 cutter bar, two independent cutter bar units, and hydraulic suspension help deliver productive mowing while allowing the cutter bar to follow changing terrain. With a recommended 95 hp PTO tractor, 540 or 1,000 rpm PTO capability, and a 2-point quick hitch with swivel gearbox, the TM1210 is suited to operators seeking broad coverage, controlled cutting height, and practical transport configuration.

Product Highlights

The TM1210 combines a broad working range with features intended to support reliable operation in varied field conditions. The 12-disc Q3 cutter bar uses 24 blades and 23 in (58.4 cm) discs to provide a 17.7 ft cutting width. Two independent cutter bar units support terrain following, while the hydraulic, nitrogen-charged accumulator suspension system helps manage cutter bar movement during operation.

Operator-focused service features include Vermeer’s Quick-Clip blade retention system and Quick-Change shear ring. A friction-disc driveline clutch supports the driveline, while standard highway lights assist with road transport. The mower is listed with 480/45x17 flotation tires and an optional swathwheel is available as a specified option.

Key Features

• Vermeer TM1210 trailed disc mower
• 17.7 ft (5.4 m) cutting width
• 24.9 ft (7.6 m) working width
• 12-disc Q3 cutter bar with 24 blades
• Two independent cutter bar units for terrain following
• Hydraulic suspension with nitrogen-charged accumulator suspension system
• Quick-Clip blade retention system
• Quick-Change shear ring
• Friction-disc driveline clutch
• Adjustable 1–3 in (2.5–7.6 cm) cut height
• 540 or 1,000 rpm drive PTO capability
• Standard highway lights
• 480/45x17 flotation tires listed by Vermeer
• Optional swathwheel

Specifications

Tractor Requirements

The Vermeer TM1210 is specified for tractors providing at least 95 hp (70.8 kW) at the PTO. The mower can operate with either a 540 rpm or 1,000 rpm PTO. Hydraulic connection requirements are two double-acting hydraulic circuits, with a specified hydraulic pressure of 1,850 psi (127.6 bar) and flow rate of 6 gpm (22.7 L/min).

Hitch and Compatibility

The mower uses a 2-point quick hitch with swivel gearbox and requires a Category II or III N connection. Compatibility is specified for tractors with a 540 or 1,000 rpm PTO, a Category II or III N 2-point quick hitch, and two double-acting hydraulic remotes. Confirm tractor capacity, hydraulic connections, hitch category, PTO configuration, and transport clearance before operation.
