NM Attachments - Class 8 Non-Rotating Bypass Grapple - 2-over-3 Tine - Heavy-Duty Boxed Design [NM-8BG-812]

NM Attachments Class 8 Non-Rotating Bypass Grapple – 2-over-3 Tine – Heavy-Duty Boxed Design is a heavy-duty demolition and material-handling attachment from NM-Attachments. Model NM-8BG-812 is identified as a non-rotating bypass grapple with a 2-over-3 tine configuration, a high-strength steel construction, AR400 steel in major wear areas, and a boxed design. It is intended for demanding applications such as severe demolition, rock handling, and waste handling, where controlled gripping and robust construction are important. A three-position stiff arm provides configuration flexibility for the grapple family.

Built for Demolition and Material Handling

The boxed design and high-strength steel construction are intended for demanding grapple work. AR400 steel is used in major wear areas to address the abrasion associated with applications such as rock and waste handling. The bypass grapple design and 2-over-3 tine arrangement provide the configuration specified for this model in the catalogue data.

As a non-rotating attachment, this grapple is described without a rotating function. The three-position stiff arm is a confirmed feature of the NM Attachments demolition-grapple family and supports adjustment between available stiff-arm positions. The attachment is suited to work where demolition material, rock, and waste must be gripped and handled by a compatible excavator.

Key Features

• NM Attachments Class 8 non-rotating bypass grapple
• 2-over-3 tine configuration
• Heavy-duty boxed design
• High-strength steel construction
• AR400 steel in major wear areas
• Three-position stiff arm
• Designed for severe demolition, rock handling, and waste handling applications

Applications

NM Attachments identifies this demolition-grapple family for severe demolition, rock handling, and waste handling applications. The grapple’s heavy-duty boxed design, high-strength steel construction, and AR400 wear areas are suited to material-handling tasks involving demanding working conditions. Confirm the excavator, hydraulic installation, and mount requirements before ordering or installation.

Specifications

Excavator Compatibility and Mount Requirements

Manufacturer family information identifies the Class 8 / 8EG23 demolition-grapple size as suitable for excavators in the 14,000–24,000 lb range. This is a related Class 8 catalogue reference and has not been confirmed as identical to product code NM-8BG-812. Exact compatibility for NM-8BG-812 should therefore be confirmed before purchase.

The mount or hitch must be specified, and the exact hitch or mount for NM-8BG-812 has not been verified. Confirm the excavator’s available mounting arrangement and all installation requirements when specifying this grapple.
