NM Attachments - Class 3 Non-Rotating Bypass Grapple - 2-over-3 Tine - Heavy-Duty Boxed Design [NM-3BG-304]

NM-Attachments Class 3 Non-Rotating Bypass Grapple – 2-over-3 Tine – Heavy-Duty Boxed Design [NM-3BG-304] is an excavator grapple listed for demanding material-handling, sorting, demolition, and site-clearing applications. Its bypass-grapple format uses opposing tine arrangements to help grip, separate, and move material, while the 2-over-3 tine configuration provides the working arrangement specified for this model. NM Attachments describes its bypass-grapple product family as using a boxed design for maximum durability, and its demolition-grapple family includes 2-over-3-tine configurations constructed with high-strength steel and AR400 steel in major wear areas. The NM-3BG-304 is identified in the catalogue as a Class 3, non-rotating model.

Key Features

• Product: NM-Attachments Class 3 Non-Rotating Bypass Grapple
• 2-over-3 tine configuration: Designed around the specified five-tine arrangement for gripping and handling material.
• Heavy-duty boxed design: The boxed construction is described by NM Attachments as supporting maximum durability in its bypass-grapple product family.
• Excavator attachment: Intended for use as an excavator grapple in material-handling and site-work applications.
• Bypass grapple format: Suitable for applications requiring material to be grasped, sorted, moved, or cleared.
• High-strength construction information: NM Attachments describes its demolition-grapple family as using high-strength steel, with AR400 steel in major wear areas.
• Non-rotating design: The catalogue identifies this model as non-rotating.

Applications

The NM-3BG-304 is suited to excavator work where a grapple is required to pick up, sort, load, or clear materials. Potential uses include demolition-site handling, vegetation and debris removal, construction-site cleanup, and general material handling. The bypass-grapple configuration is intended for controlled gripping and separation of material rather than rotating positioning.

Construction and Design

The heavy-duty boxed design is a defining feature of this grapple. NM Attachments identifies boxed construction as a durability feature within its bypass-grapple product family. The manufacturer also states that its demolition grapples are available in a 2-over-3-tine configuration and use high-strength steel, including AR400 steel in major wear areas. These construction details support the grapple’s intended use in demanding excavator applications.

Specifications

Important Product Information

The exact NM-3BG-304 model is listed in the catalogue with the specifications shown above. Dimensions, operating weight, hydraulic requirements, transport width, and specific excavator compatibility are not included in the available product information. Confirm the excavator’s attachment interface and operating requirements before ordering or installation.
