NM Attachments - 16" Class 2 Heavy-Duty Tooth Bucket - 4 CAT-Style Teeth - 1.1 cu ft, AR400 Wear Areas [NM-2HD-16]

The NM Attachments 16" Class 2 Heavy-Duty Tooth Bucket is a four-tooth excavator bucket designed for excavators in the 3,000–6,000 lb machine class. With a 16-inch working width and 1.1 cu ft capacity, it is suited to digging and material-handling work in sand, gravel, clay, and trenching applications. The bucket uses a standard CAT-style tooth configuration at the product-family level, while AR400 wear steel is reported for key wear areas including the bottom wear straps, side wear plates, and side cutters. The mount or interface must be specified when ordering.

Heavy-Duty Excavator Bucket Performance

This NM Attachments tooth bucket is intended for demanding excavation work where a toothed cutting edge is preferred over a smooth digging edge. Its four-tooth configuration helps engage and penetrate common jobsite materials, while the 16-inch width provides a focused digging profile for trenching and controlled excavation.

The product-family construction is described as high-grade structural steel with AR400 steel in wear areas. These wear areas include the bottom wear straps, side wear plates, and side cutters, helping reinforce components exposed to repeated contact with soil, aggregate, and other abrasive materials. Tooth options are available across the product family; this listing specifies the standard CAT-style tooth configuration at the product-family level.

Key Features

• 16-inch bucket width for focused excavation and trenching work
• 1.1 cu ft rated capacity
• Four-tooth configuration
• Standard CAT-style teeth configuration at the product-family level
• High-grade structural steel construction at the product-family level
• AR400 wear steel in reported bottom wear straps, side wear plates, and side cutters
• Designed for use in sand, gravel, clay, and trenching applications at the product-family level
• Recommended for excavators in the 3,000–6,000 lb machine class
• Mount must be specified when ordering

Applications

The bucket is designed for general excavation and material-handling tasks involving sand, gravel, and clay. Its toothed profile is also suited to trenching applications where a narrow, controlled digging path is beneficial. The 1.1 cu ft capacity supports efficient handling of excavated material while maintaining a 16-inch working width.

Specifications

Compatibility and Ordering Requirements

This bucket is intended for excavators in the 3,000–6,000 lb machine class. The mount must be selected and specified when ordering because the available catalogue information does not identify a single universal mount or hitch/interface. Confirm the required mount before purchase to ensure compatibility with the excavator.
