NM Attachments - 12" Class 6 Heavy-Duty Tooth Bucket - 3 CAT-Style Teeth - 3.75 cu ft, AR400 Wear Areas [NM-6HD-12]

The NM Attachments NM-6HD-12 12-inch Class 6 Heavy-Duty Tooth Bucket is built for demanding excavator work in sand, gravel, clay, and utility trenching applications. Part of NM Attachments’ 6HD series, this tooth bucket combines high-grade structural steel construction with AR400 steel in key wear areas, including the bottom wear straps, side wear plates, and side cutters. Its standard CAT-style tooth configuration provides an aggressive digging edge for material penetration, making it suited to general excavation and trenching work with compatible 6–7 ton excavators.

Heavy-Duty Construction for Excavation Work

The NM-6HD-12 is designed as a durable digging attachment for applications where the bucket encounters abrasive material and repeated ground contact. The main structure uses high-grade structural steel, while AR400 wear steel is used throughout the identified wear areas. This includes the bottom wear straps, side wear plates, and side cutters, helping reinforce the areas exposed to abrasion during digging, loading, and trenching.

With a nominal working width of 12 inches, the bucket is configured for narrower excavation work and trenching. The supplied product specification identifies a capacity of 3.75 cubic feet and three CAT-style teeth, providing a defined digging profile for breaking into and moving common excavation materials.

Key Features

• NM Attachments 6HD-series excavator tooth bucket
• 12-inch nominal bucket width for focused excavation and trenching
• Heavy-duty construction for compatible 6–7 ton excavators
• High-grade structural steel main construction
• AR400 steel in the bottom wear straps, side wear plates, and side cutters
• Three standard CAT-style teeth
• Listed capacity of 3.75 cubic feet
• Suitable for sand, gravel, clay, and utility trenching for gas and water lines

Applications

The NM-6HD-12 is intended for general excavation and material-handling tasks involving sand, gravel, and clay. Its tooth-equipped digging edge is also suited to utility trenching for gas and water lines, where a narrower bucket width can support focused trench excavation. The AR400 wear areas are designed for the abrasive contact zones of the bucket, including the bottom, side plates, and side cutters.

Specifications

Compatibility and Tractor Requirements

This attachment is listed for use with NM Attachments 6HD-series excavators and is intended for excavators approximately in the 6–7 ton class, or approximately 12,000–14,000 lb. Confirm that the excavator’s attachment interface is compatible before ordering. Specific hitch, pin, hydraulic, machine mounting, and dimensional requirements are not specified in the supplied product information.
