NM Attachments - 12" Class 6 Heavy-Duty Spade-Tooth Bucket - 3 Spade Teeth - 3.75 cu ft, AR400 Wear Areas [NM-6HD-12S]

SKU NM-6HD-12S
Starting at $2,92800
Starting at $2,92800

Add your items to the Cart to begin to build and price your package!


When you're ready to take the next step, please reach out to us for a quote.

*Pricing shown at MSRP and may not include available Timberstar Tractor or Manufacturer discounts.
*Finance rates, payment calculations, whether or not you need a down payment, all available through our sales staff.
*Pricing may not include freight, assembly, finance, delivery, or pdi fees.
*Manufacturer pricing subject to change without notice.
*Manufacturer sales promotions valid unitl the end of the month they were issued in.
*Price match available for many brands we carry.

Description

NM-Attachments NM-6HD-12S 12" Class 6 Heavy-Duty Spade-Tooth Bucket is an excavator tooth bucket designed for demanding digging and trenching work. This bucket features a 12-inch working width, three spade teeth, a listed 3.75 cu. ft. capacity, and AR400 steel in key wear areas. Its high-grade structural-steel construction supports use in sand, gravel, clay, and trenching applications, while the tooth configuration is suited to penetrating and loosening materials during excavation.

Built for Digging and Trenching

The NM-6HD-12S combines a heavy-duty bucket design with a spade-tooth configuration for excavation tasks that require material penetration. NM-Attachments constructs its tooth buckets from high-grade structural steel and uses AR400 steel in wear areas, including the bottom wear straps, side wear plates, and side cutters. These reinforced areas are intended to help protect the bucket where contact with abrasive material is expected.

The bucket uses a standard CAT-style tooth configuration, with various tooth options available from the manufacturer. The catalogue designation identifies this model with three spade teeth, providing a tooth-equipped cutting edge for working through sand, gravel, clay, and trenching conditions such as gas and water line trenches.

Key Features

  • Manufactured by NM-Attachments
  • 12-inch working width as identified by the model designation
  • Class 6 heavy-duty spade-tooth bucket designation
  • Three spade teeth
  • Listed 3.75 cu. ft. bucket capacity
  • High-grade structural-steel construction
  • AR400 steel wear areas
  • AR400 bottom wear straps, side wear plates, and side cutters
  • Standard CAT-style tooth configuration
  • Various tooth options available
  • Suitable applications include sand, gravel, clay, and trenching

Applications

The NM-6HD-12S is intended for excavation work involving sand, gravel, and clay, as well as trenching for gas and water lines. Its spade-tooth design is suited to digging applications where a toothed edge is preferred for engaging and breaking into the material. AR400 wear areas provide reinforced contact surfaces at the bottom, sides, and side cutters for demanding bucket use.

Specifications

Brand NM-Attachments
Model NM-6HD-12S
Product type Excavator tooth bucket
Bucket designation 12" Class 6 heavy-duty spade-tooth bucket
Working width 12 in
Bucket capacity 3.75 cu. ft.
Tooth count 3 spade teeth
Construction material High-grade structural steel
Wear-area material AR400 steel
Wear areas Bottom wear straps, side wear plates, and side cutters
Tooth configuration Standard CAT-style
Product code NM-6HD-12S

Tooth Options

The manufacturer identifies various tooth options for its tooth buckets. Confirm the required tooth option and attachment details before ordering to ensure the bucket is appropriate for the intended excavator and application.
