HLA Attachments - Four-Prong Bale Spear for Two Round Bales - 39" Tine (34" Usable Length) - 4,000 lb Capacity - Hay and Bale Handling [LA-FE10039BO500]

HLA Attachments FE10039BO500 Four-Prong Bale Spear is a loader-mounted hay-handling attachment purpose-built to carry two round bales, each measuring up to 6 ft in diameter. Its wide 100 in frame supports four Kverneland tines positioned to handle a pair of bales, helping operators move and organize hay efficiently. Each primary tine is 39 in long with 34 in of usable length, while the attachment is rated for a 4,000 lb capacity at a 24 in load center. This configuration includes HLA’s BO500 quick-attach mounting code for compatible loaders and carriers.

Purpose-Built for Two Round Bales

Unlike a single-bale spear, the FE10039 is designed specifically for handling two round bales at once. The four primary tines are arranged across the 100 in frame, with the tines spaced 29 in apart on each side. This layout provides dedicated tine placement for carrying two bales, each up to 6 ft in diameter.

The attachment is suitable for loader-mounted hay and bale-handling work, including moving bales around the farm, transferring hay from storage areas, organizing bale rows, and supporting feeding or loading operations. Its approximately 340 lb attachment weight combines a substantial bale-handling frame with a clearly defined rated capacity.

Four Kverneland Tines

The FE10039BO500 is equipped with four Kverneland tines. Each tine measures 39 in overall and provides 34 in of usable length for engaging the bales. The use of four primary tines allows the attachment to support its two-bale configuration across both sides of the frame.

Rated capacity is 4,000 lb when measured at a 24 in load center. Operators should consider the combined weight of the bales, the stated load-center rating, and the operating capacity of the loader or carrier before use.

Key Features

• Designed specifically to carry two round bales
• Handles two round bales, each up to 6 ft in diameter
• Four Kverneland primary tines
• 39 in overall tine length
• 34 in usable tine length
• Tines spaced 29 in apart on each side
• 4,000 lb rated capacity at a 24 in load center
• Wide 100 in bale-handling frame
• Approximately 340 lb attachment weight
• BO500 quick-attach mounting configuration

Compatibility and Mounting

This model combines the HLA FE10039 bale spear with the BO500 quick-attach mounting code. The BO500 mount is commonly used by HLA for universal skid-steer-style quick-attach carriers. Compatibility must be confirmed against the exact loader or carrier before purchase or installation, as quick-attach dimensions and carrier configurations can vary.

The loader or carrier must also be suitable for the approximately 340 lb attachment weight and the intended bale load. Its operating limits should be evaluated with the attachment installed and with consideration for the FE10039’s 4,000 lb rating at a 24 in load center.
