HLA Attachments - 96" Manure Fork 13-Cranked Tines 7 7/8" - Manure and Livestock Handling [LA-MFE96BO500]

HLA Attachments MFE96BO500 96-Inch Manure Fork is a wide livestock-handling attachment designed for efficient manure handling with compatible loaders and machines. Its 13 cranked Conus I Kverneland tines provide superior penetration, while the 31-inch usable tine length offers ample working reach for moving manure and other livestock-related material. Configured with HLA’s BO500 skid-steer-style quick-attach mount, this fork combines a 96-inch working width with evenly spaced tines for productive work around barns, yards, pens, and other livestock facilities.

Built for Effective Manure Handling

The MFE96 uses 13 heavy-duty cranked Kverneland tines positioned on 7-7/8-inch centres. Each tine measures 35 inches overall and provides 31 inches of usable length. The cranked tine design supports effective material penetration, helping the fork enter manure and livestock material cleanly during loading, carrying, and cleanup work.

With its 96-inch working width, the fork covers a broad area in each pass. This makes it well suited to operators looking to handle larger volumes or work efficiently across wide barn alleys, livestock yards, and manure storage areas. The flat top of the fork also acts as a level indicator, giving the operator a useful visual reference when positioning the attachment.

Key Features

• 96-inch working width for broad material coverage
• 13 cranked Kverneland tines
• Conus I tine configuration
• 35-inch overall tine length
• 31-inch usable tine length
• 7-7/8-inch tine spacing for consistent material support
• Cranked tine design provides superior penetration
• Flat top acts as a convenient level indicator
• BO500 quick-attach mounting configuration
• Designed as a manure fork and livestock-handling attachment

BO500 Quick-Attach Configuration

This configured model is supplied with HLA mounting code BO500. HLA identifies BO500 across numerous skid-steer-style quick-attach carrier applications, allowing the attachment to be connected and removed through a quick-attach interface rather than a permanent mounting arrangement.

Because mounting dimensions and carrier arrangements can vary by machine and loader, compatibility should be confirmed against HLA’s mounting-code fitment information before purchase. The machine must use the BO500-compatible quick-attach configuration.

Applications

The MFE96BO500 is intended for manure and livestock-handling work. Its combination of wide coverage, long usable tine length, and cranked tine geometry makes it a practical choice for gathering, lifting, carrying, and repositioning manure and related livestock material. The approximately 590-pound manufacturer-listed base-model weight should also be considered when matching the attachment to the operating capacity of the carrier machine.

Specifications

Compatibility

Compatible with machines and loaders using HLA mounting code BO500. Loader-specific fitment should be verified against HLA’s applicable mounting-code tables before ordering. Carrier capacity should be evaluated with consideration for the attachment’s approximately 590-pound manufacturer-listed base-model weight and the weight of the material being handled.
