HLA Attachments - 96" Extreme Duty Low Profile Skid Steer Bucket with 9 Ripper Teeth - Low-Profile Skid Steer Attachment [LA-SBLP96XDT9BO500]

HLA Attachments 96-Inch Extreme Duty Low Profile Skid Steer Bucket with 9 Ripper Teeth combines heavy-duty construction, generous capacity, and improved cutting-edge visibility in a robust skid-steer attachment. Manufacturer model SBLP96XDT9 features a lower back and longer base that help the operator see the cutting edge, while nine ripper teeth provide an aggressive working edge. Its 96-inch inside width, 23.3-cubic-foot SAE heaped capacity, reinforced top lip, extra skid bars, and BO500 skid-steer-style quick-attach mount make it a substantial bucket for demanding material-handling and bucket applications.

Extreme-Duty Bucket Construction

The main bucket is manufactured from 5/16-inch material to withstand demanding working conditions. Its 1/4-inch end plates are reinforced by a 1/2-inch stiffener bar, while heavy-duty top-lip bracing adds structural support across the bucket. Extra skid bars beneath the bucket reinforce the underside in areas exposed to regular ground contact.

At the working edge, the bucket uses a substantial 1-by-8-inch beveled cutting edge. Nine ripper teeth are positioned across the bucket to provide a toothed configuration. Standard bolt-on side cutters complete the cutting-edge arrangement and can be serviced separately from the bucket body.

Low-Profile Design and Capacity

The low-profile configuration uses a lower back and longer base to improve the operator’s view of the cutting edge. This design helps with bucket positioning while retaining a 34-inch bucket depth and 19-inch bucket height. The 96-inch inside width provides broad coverage, and manufacturer-rated capacity is 16.8 cubic feet struck or 23.3 cubic feet SAE heaped.

Self-cleaning tapered end plates are designed to reduce material buildup at the sides of the bucket. Together with the beveled cutting edge, side cutters, ripper teeth, and reinforced construction, this design provides a practical combination of visibility, capacity, and durability.

Key Features

• 96-inch inside bucket width
• Extreme-duty, low-profile skid-steer bucket design
• Nine ripper teeth
• 5/16-inch main bucket material
• 1/4-inch end plates reinforced with a 1/2-inch stiffener bar
• 1-by-8-inch beveled cutting edge
• Heavy-duty top-lip bracing
• Extra skid bars beneath the bucket
• Lower back and longer base for improved cutting-edge visibility
• Standard bolt-on side cutters
• Self-cleaning tapered end plates to reduce material buildup
• BO500 skid-steer-style quick-attach mount
• 16.8-cubic-foot struck capacity
• 23.3-cubic-foot SAE heaped capacity

Compatibility

This configuration is compatible with skid-steer loaders and loader carriers equipped with the HLA BO500 skid-steer-style quick-attach interface. Confirm that the carrier has the correct attachment interface and sufficient rated operating capacity for the bucket’s approximate 1,130-pound weight and the intended load.

Power Requirements

This bucket does not require PTO or hydraulic power. Operation is through the compatible loader or skid-steer carrier and its BO500 quick-attach interface.
