HLA Attachments - 84" Wide Rubber Feed Alley Scraper - Livestock and Farm Scraper [LA-RFH84BO500]

HLA Attachments RFH84BO500 84-Inch Rubber Feed Alley Scraper is a hydraulically angled livestock and farm scraper designed for cleaning feed alleys, mangers, and other concrete or tiled-floor areas. Its broad 84-inch working width helps cover more surface with each pass, while the 24-inch-high rubber blade moves material effectively without the rigid scraping edge of a steel blade. Hydraulic power angling allows the operator to direct material to either side from the carrier, making the scraper a practical choice for routine cleanup around livestock facilities.

Efficient Feed Alley and Manger Cleanup

The RFH84 scraper is built for applications where a wide rubber blade is preferred for working over concrete or tiled floors. It can be used to move feed, manure, bedding, and other loose material along an alley or toward a collection point. The 84-inch width balances productive coverage with manoeuvrability in farm and livestock environments.

A 24-inch blade height provides useful carrying capacity as material gathers in front of the scraper. Because the blade can be angled hydraulically, the operator can windrow or discharge material toward the left or right instead of only pushing straight ahead. This makes it easier to clean along walls, direct material away from feeding areas, or work progressively across a floor.

Hydraulic Power Angling

The scraper hydraulically angles up to 45 degrees in either direction. Power angling enables blade adjustments from the operating position when connected to a carrier with auxiliary hydraulics. The angle can be changed to suit the direction of travel, working area, and preferred discharge side.

An optional HK90 hydraulic hose kit is available and includes 90-inch hoses with flat-faced couplers. An optional SHMK spring hose mount kit is also available to help support and manage the hydraulic hoses.

Key Features

• 84-inch working width for efficient coverage of livestock and farm alleys
• 24-inch-high rubber scraper blade
• Suitable for concrete or tiled-floor mangers
• Hydraulic power-angle operation
• Angles up to 45 degrees to the left or right
• BO500 universal/skid-steer-style quick-attach mounting configuration
• Approximately 555 lb base-unit weight
• Optional 90-inch hydraulic hose kit with flat-faced couplers
• Optional spring hose mount kit for hose support

Compatibility

The RFH84BO500 is configured with HLA Attachments mounting code BO500 for universal/skid-steer-style quick-attach carriers. BO500 is also listed for certain tractor loaders equipped with a skid-steer carrier. Loader-specific fitment should be confirmed against HLA Attachments’ mounting guide before purchase.

Carrier and Hydraulic Requirements

A compatible BO500 universal/skid-steer-style quick-attach carrier is required. The carrier must also have auxiliary hydraulics to operate the scraper’s power-angle function. Hydraulic flow and pressure requirements are not specified for this model.
