HLA Attachments - 84" Rubber Free Stall Scraper Heavy Duty with Back Drag - Livestock and Farm Scraper [LA-RSBDH84BO500]

HLA Attachments RSBDH84BO500 84-Inch Heavy-Duty Rubber Free-Stall Scraper with Back Drag is built for efficient livestock and farm clean-out work. Its 84-inch working width, deeper scraper profile, and 18-inch-high heavy-duty rubber provide useful capacity while promoting smooth operation across free-stall and other farm surfaces. An enclosed frame with a splash plate helps contain material during operation, while the integrated back-drag design makes it easier to pull material out of corners and other areas that are difficult to clean with forward scraping alone. This BO500 variant is equipped with a universal skid-steer quick-attach mounting interface.

Heavy-Duty Scraping for Livestock and Farm Use

The RSBDH84 is designed around a deep scraper configuration that handles a greater volume of material while operating smoothly. Its wide rubber edge provides 84 inches of working coverage, helping reduce the number of passes required when cleaning free-stall areas and other suitable farm surfaces.

The 18-inch-high scraping edge is made from heavy-duty rubber for longer service life. Rubber provides a broad, flexible contact edge, while the enclosed frame and splash plate support cleaner material control during scraping. The scraper has an approximate operating weight of 545 lb.

Back Drag for Corner Clean-Out

Cleaning along walls, in corners, and around confined spaces can be challenging with a conventional forward-only scraper. The RSBDH84BO500 includes a back-drag system that allows the operator to pull material away from corners before collecting or moving it with the main scraping edge. This dual-purpose configuration makes the attachment useful for routine clean-out work where access and maneuvering space may be limited.

Key Features

• 84-inch working width: Provides broad coverage for livestock and farm scraping applications.
• Heavy-duty rubber edge: Designed for longer service life during regular clean-out work.
• 18-inch rubber height: Creates a deep scraping profile for handling a greater volume of material.
• Deeper scraper construction: Supports increased capacity and smoother operation.
• Enclosed frame: Provides a robust structure around the scraper assembly.
• Integrated splash plate: Helps manage material while the scraper is in operation.
• Back-drag design: Allows material to be pulled out of corners and other difficult-to-reach areas.
• Universal skid-steer quick attach: BO500 mounting configuration provides a common quick-attach interface.

Attachment Compatibility

This model is the RSBDH84BO500 configuration and uses the BO500 universal skid-steer quick-attach mounting interface. Confirm that the intended carrier has a compatible universal skid-steer quick-attach carrier and is suitable for the attachment’s approximate 545 lb weight before use.

Specifications
