HLA Attachments - 84" Rubber Free Stall Scraper Heavy Duty Standard - Livestock and Farm Scraper [LA-RSH84BO500]

HLA Attachments RSH84BO500 84-Inch Heavy-Duty Rubber Free Stall Scraper is a fixed livestock and farm scraper designed for moving material efficiently through free stalls, barns and other farm areas. Its 84-inch working width, 18-inch-high heavy-duty rubber and deeper scraper profile provide useful material capacity while supporting smooth operation. An enclosed frame with a splash plate helps contain material during use, while the BO500 universal skid-steer-style quick-attach interface allows the scraper to be connected to loaders equipped with a compatible carrier.

Heavy-Duty Scraping for Livestock and Farm Use

The RSH84 is built around a heavy-duty rubber scraping edge selected for longer service life. The flexible rubber follows the working surface while moving manure and other loose farm material, making the scraper suitable for routine livestock-area cleanup. Its deeper design increases the volume of material that can be handled in each pass and contributes to smoother operation.

An enclosed frame and integrated splash plate help manage material as it is pushed. With an 84-inch nominal width, the scraper offers broad coverage without requiring hydraulic functions. This is the Heavy Duty Standard configuration and does not include a back-drag feature.

Key Features

• 84-inch scraping width for efficient coverage of livestock and farm working areas
• 18-inch-high heavy-duty rubber for longer service life
• Deeper scraper profile for greater material volume and smoother operation
• Enclosed frame with splash plate to help contain material during scraping
• Heavy Duty Standard configuration without back-drag
• Fixed, non-hydraulic design with no stated hydraulic requirements
• BO500 universal skid-steer-style quick-attach interface

Simple, Fixed Operation

This scraper uses a straightforward fixed design rather than hydraulic movement. No hydraulic requirements are stated, reducing connection steps and making it a practical choice for regular scraping work where powered angle, back-drag or other hydraulic functions are not needed. The standard configuration is intended for forward scraping and material-pushing applications.

Loader Compatibility

The RSH84BO500 is fitted with HLA Attachments’ BO500 attachment-side interface, part of the universal skid-steer interface family. It is intended for loaders equipped with a universal skid-steer-style quick-attach carrier. Because loader carriers can vary, the specific loader and carrier should be checked to confirm fit before purchase or installation.

Loader Requirements

No PTO or hydraulic connection is stated for this fixed scraper. Ensure the loader has a compatible universal skid-steer-style quick-attach carrier and adequate operating capacity for the attachment and the material being handled. The manufacturer lists the approximate base-model RSH84 scraper weight as 380 lb; a separate combined weight for the BO500-mounted configuration is not published.

Specifications
