HLA Attachments - 84" Manure Fork 11-Cranked Tines 8 1/8" - Manure and Livestock Handling [LA-MFE84BO500]

The HLA Attachments MFE84BO500 84-inch Manure Fork is designed for manure and livestock-handling applications where effective penetration, broad coverage, and a universal skid-steer quick-attach connection are required. Its 11 cranked Conus I Kverneland tines are arranged on 8-1/8-inch centres, providing an evenly distributed working layout across the 84-inch width. Each tine measures 35 inches overall and offers 31 inches of usable length for engaging and carrying material. The BO500 mounting configuration fits universal skid-steer quick-attach carriers and compatible loader models using this interface.

Designed for Manure and Livestock Handling

The MFE84BO500 combines an 84-inch working width with 11 cranked tines to create a practical attachment for routine farm and livestock-handling work. HLA lists superior penetration as a key benefit of the tine design, helping the fork enter suitable material efficiently.

The tines are genuine cranked Kverneland components with a Conus I profile. Their 35-inch overall length provides 31 inches of usable tine length, while the consistent 8.125-inch spacing supports material across the width of the attachment. This configuration is well suited to operators who need a dedicated manure fork rather than a grapple-equipped attachment.

Operator-Friendly Level Reference

The fork’s flat top also acts as a level indicator. From the operator’s position, this provides a simple visual reference when positioning the attachment. It can help the operator judge the fork’s orientation while approaching, entering, carrying, or placing material.

BO500 Quick-Attach Configuration

This configured model includes HLA’s BO500 mounting-interface code, identifying a universal skid-steer quick-attach hitch. The quick-attach configuration allows the manure fork to be connected to universal skid-steer quick-attach carriers and loader models listed by HLA as using the BO500 interface.

Always confirm that the carrier’s attachment interface matches the BO500 universal skid-steer quick-attach configuration before purchase or installation. The carrier must also be suitable for the attachment’s approximately 520 lb weight and the intended operating load.

Key Features

• 84-inch manure fork for manure and livestock-handling applications
• 11 cranked Kverneland tines
• Conus I tine configuration
• 35-inch overall tine length
• 31-inch usable tine length
• Tines positioned on 8-1/8-inch centres
• Manufacturer-listed superior penetration
• Flat top functions as a visual level indicator
• BO500 universal skid-steer quick-attach mounting configuration
• Approximate attachment weight of 520 lb

Compatibility

The HLA Attachments MFE84BO500 is compatible with:

• Universal skid-steer quick-attach carriers
• Loader models listed by HLA as using the BO500 skid-steer quick-attach interface

Compatibility is determined by the carrier interface. Verify the loader or carrier’s hitch style and operating capacity before attaching or using the manure fork.

Specifications
