HLA Attachments - 72" Wide Rubber Feed Alley Scraper - Livestock and Farm Scraper [LA-RFH72BO500]

HLA Attachments RFH72BO500 72-Inch Rubber Feed Alley Scraper is a hydraulic power-angle livestock and farm scraper designed for cleaning feed alleys, mangers, and similar areas where a rubber scraping edge is preferred. Its 72-inch working width covers a practical area with each pass, while the 24-inch-high blade helps move accumulated material efficiently. The rubber blade is easy on concrete and tiled-floor mangers, making this attachment well suited to routine cleaning around livestock facilities. Hydraulic angling provides up to 45 degrees of adjustment in either direction, allowing material to be directed left or right without manually repositioning the blade.

Efficient Feed-Alley and Manger Cleaning

The RFH72 combines a broad rubber blade with hydraulic angle control for adaptable cleaning in barns and other livestock areas. Operators can run the blade straight for direct pushing or angle it to windrow and direct material toward the desired side. This power-angle design is particularly useful when cleaning along feed alleys or working around areas where material needs to be moved progressively toward a collection point.

At approximately 525 lb, the scraper is built as a substantial loader attachment while remaining straightforward to connect through its BO500 mounting configuration. This model is supplied with HLA’s skid-steer-style quick-attach interface, helping reduce attachment changeover time when used with a compatible loader carrier.

Key Features

• 72-inch working width for productive coverage in feed alleys, mangers, and livestock facilities
• 24-inch-high rubber blade for moving accumulated material
• Hydraulic power angle for convenient in-cab blade positioning
• 45-degree angle range in either direction to direct material left or right
• Rubber scraping edge that is easy on concrete and tiled-floor mangers
• BO500 mounting code with a skid-steer-style quick-attach interface
• Approximately 525 lb catalogue weight
• Designed for feed-alley, manger, livestock, and general farm-cleaning applications

Hydraulic Power-Angle Operation

The blade can be hydraulically angled as much as 45 degrees to the left or right. This gives the operator control over where scraped material travels and reduces the need to stop and manually adjust the attachment. A suitable hydraulic connection is required to operate the power-angle function.

Hydraulic flow, pressure, hose, and coupler requirements are not specified. Before use, confirm that the carrier’s auxiliary hydraulic system and connections are appropriate for the attachment. HLA lists an optional HK90 hose kit with 90-inch hoses and flat-faced couplers, as well as an optional SHMK spring hose-mount kit for hose support.

Compatibility

This configured model uses the HLA BO500 skid-steer-style quick-attach mounting system. Because loader carriers and quick-attach interfaces can vary, fitment should be confirmed against HLA’s mounting-code information and the specifications of the intended loader before ordering.

Specifications
