HLA Attachments - 66" Compact Brush Grapple - Hydraulic Material Handling [LA-BRGC66BO500]

HLA Attachments BRGC66BO500 66-Inch Compact Brush Grapple is a hydraulically operated material-handling attachment designed for brush, branches, and land-clearing debris. Its 66-inch working width provides broad coverage, while the single grapple arm opens to 38 inches from the ground to the grapple point to capture bulky, irregular loads. AR400 tine tips and grapple tips reinforce key contact areas, and the BO500 skid-steer-style quick-attach configuration makes this model suitable for compatible carriers.

Compact Grapple for Brush and Debris Handling

The BRGC66 combines a compact 28-inch overall height and 33-inch overall depth with a practical 66-inch working width. Tines spaced 6 inches on center support brush and similar material while allowing loose dirt and smaller debris to pass between them. This configuration is well suited to property cleanup, vegetation removal, brush collection, and general land-clearing work.

A single hydraulic grapple arm helps secure uneven material during pickup and transport. The attachment is supplied with one 2-1/2 x 8-inch hydraulic cylinder, giving the operator hydraulic control over the grapple. Its approximate 455-pound attachment weight should be considered when confirming carrier lift capacity and operating limits.

Key Features

• 66-inch working width for collecting and handling brush, branches, and land-clearing debris
• Maximum opening of 38 inches, measured from the ground to the grapple point
• Single grapple arm for securing bulky and irregular material
• AR400 tine tips and grapple tips at critical contact points
• Tines spaced 6 inches on center
• Supplied with one 2-1/2 x 8-inch hydraulic cylinder
• BO500 skid-steer-style quick-attach mounting configuration
• Compact 28-inch overall height and 33-inch overall depth
• Approximate attachment weight of 455 pounds

Hydraulic Operation

The grapple is hydraulically operated and includes one 2-1/2 x 8-inch cylinder. Hydraulic flow, operating pressure, hoses, and couplers are not specified. Confirm that the carrier has a suitable auxiliary hydraulic circuit and obtain the appropriate hose and coupler arrangement before installation.

Available hose-related options include the HK90 90-inch hose kit with flat-faced couplers, the HK9090 90-inch hose kit with 90-degree flat-faced couplers, and the SHMK spring hose-mount kit.

Compatibility

This configured model uses the HLA BO500 skid-steer-style quick-attach mount. It is intended for skid-steer-style quick-attach carriers compatible with that mounting configuration. Verify the carrier’s mounting interface, auxiliary hydraulic connections, lift capacity, and operating limits before use.
