HLA Attachments - 5,500 lb 5500 lbs Rotating Pallet Fork 54" - Material Handling Fork Attachment [LA-HDR5554BO500]

HLA Attachments HDR5554BO500 Rotating Pallet Fork combines a 5,500 lb rated carriage, 54-inch adjustable tines, and hydraulic rotation in a heavy-duty material-handling attachment. Designed for equipment fitted with a universal skid-steer-style quick-attach carrier, this rotating fork provides up to 180 degrees of movement for a full dump to the left. Its hydraulic-cylinder-powered mechanism delivers smooth, contoured rotation, making it a practical choice for handling, positioning, and dumping palletized or fork-supported materials.

Hydraulic Rotation for Efficient Material Handling

The HDR5554BO500 expands the functionality of a conventional pallet fork by adding hydraulic rotation. The carriage can rotate 180 degrees to the left, allowing the operator to pick up suitable loads with the fork tines and then rotate the attachment for controlled placement or a full left-side dump. Hydraulic-cylinder actuation provides smooth operation throughout the rotation range.

This rotating design can reduce the need for additional equipment or repeated machine repositioning when an application calls for both lifting and dumping. It is suited to material-handling work where a standard fixed fork carriage would not provide the required range of movement.

5,500 lb Rated Carriage and 54-Inch Tines

The attachment features a 5,500 lb rated carriage for demanding material-handling applications. Its 54-inch pallet-fork tines provide substantial support beneath compatible pallets and loads. The tine positions are adjustable, allowing the fork spacing to be set for different pallet dimensions and material configurations.

The base HDR5554 attachment has an approximate manufacturer-stated weight of 880 lb. The manufacturer does not separately specify whether the configured BO500 mounting interface changes that weight.

Key Features

• 5,500 lb rated pallet-fork carriage
• 54-inch adjustable pallet-fork tines
• Hydraulic-cylinder-powered rotation
• Smooth, contoured rotating action
• Rotates 180 degrees for a full dump to the left
• BO500 universal skid-steer quick-attach interface
• Heavy-duty material-handling configuration
• Approximately 880 lb base attachment weight

BO500 Quick-Attach Interface

This configuration is equipped with HLA Attachments’ BO500 interface, identified as a universal skid-steer quick attach. It is intended for equipment fitted with a corresponding universal skid-steer-style quick-attach carrier. The quick-attach configuration provides a convenient mounting arrangement for moving the rotating pallet fork between compatible machines or changing attachments as work requirements change.

Compatibility

The HDR5554BO500 is designed for equipment equipped with a universal skid-steer-style quick-attach carrier. Because carrier dimensions, hydraulic connections, lift capacities, and operating limits can vary between machines, final fit and suitability should be confirmed against the specific loader or carrier model before purchase or operation.

Hydraulic Requirements

A hydraulic connection is required to operate the attachment’s rotation cylinder. HLA Attachments does not publish a verified hydraulic flow or pressure requirement for this configured model. Confirm that the host machine has appropriate auxiliary hydraulic capability and suitable connections for attachment operation.
