HLA Attachments - 42" Tine For HD55 Pallet Fork (Domestic Tine) - Replacement Tine [LA-HD542]

SKU LA-HD542
Starting at $36000
Starting at $36000

Add your items to the Cart to begin to build and price your package.


When you're ready to take the next step, please reach out to us for a quote, or complete the checkout process to reserve your items in store. (The online checkout just emails us a copy of the items you are interested in, we then reach out to you to confirm everything.)

Showing pricing online is difficult, here's why:
*Pricing shown at MSRP and may not include available Timberstar Tractor or Manufacturer discounts.
*Finance rates, payment calculations, whether or not you need a down payment, all available through our sales staff.
*Online pricing does not include freight, assembly, finance, delivery, or pdi fees.
*Our manufacturer's pricing is subject to change without notice.
*Manufacturer sales promotions valid unitl the end of the month they were issued in.
*Price match available for many brands we carry.

Description

HLA Attachments HD542 42-Inch Replacement Tine is a domestic-manufactured, solid forklift tine designed for the HLA HD55 5,500 lb Heavy Duty Pallet Fork. Featuring a Class II hook-type mounting system and a robust 1-1/2 x 4-inch cross-section, it provides a direct replacement option for a worn or damaged tine on a compatible HD55 pallet-fork assembly. This replacement component is sold individually, making it possible to replace one tine without purchasing a complete pallet-fork attachment.

Domestic Replacement Tine for the HLA HD55

The HD542 is the domestic tine variant specified for the HLA HD55 pallet-fork series. Its solid forklift-tine construction is suited to material-handling applications performed with the compatible fork assembly, including lifting, carrying, positioning, and loading palletized materials.

With a tine length of 42 inches, the HD542 matches the specified tine configuration for the HD55 Heavy Duty Pallet Fork. The Class II hook-type design allows the tine to mount to the compatible pallet-fork frame. Before ordering, confirm the manufacturer part number, tine dimensions, and mounting class against the existing fork assembly.

Key Features

  • Genuine HLA Attachments replacement pallet-fork tine
  • Domestic-manufactured tine variant
  • 42-inch tine length
  • Solid forklift-tine construction
  • 1-1/2 x 4-inch tine cross-section
  • Class II hook-type mounting
  • Designed for the HLA HD55 Heavy Duty Pallet Fork
  • Sold individually as one replacement tine

Compatibility

This replacement tine is compatible with the HLA HD55 5,500 lb Heavy Duty Pallet Fork. The HD55 fork assembly is rated at 5,500 lb at a 24-inch load center. This rating applies to the compatible complete HD55 pallet-fork assembly and should not be interpreted as a separate capacity rating for one replacement tine.

The HD542 is the domestic tine version. It is distinct from the HD542W economy tine, so the part number should be checked carefully when selecting a replacement.

Specifications

Brand HLA Attachments
Product type Replacement pallet-fork tine
Manufacturer part number HD542
Catalogue SKU LA-HD542
Tine length 42 in
Tine cross-section 1-1/2 x 4 in
Construction Solid forklift tine
Mounting Class II hook type
Tine variant Domestic tine
Compatible fork series HLA HD55 pallet fork
Compatible assembly capacity 5,500 lb at 24 in load center
Unit of measure Each

Ordering Information

One HD542 tine is included per unit ordered. If both tines require replacement, order the necessary quantity individually. Verify that the existing attachment is an HLA HD55 pallet fork and that it uses a 42-inch, Class II hook-type tine with the specified 1-1/2 x 4-inch cross-section before purchase.
