BRABER - 86" Heavy-Duty 3-Point Disc Harrow - Notched Front & Rear Discs with Scrapers - Cat 1/2, 40-65 HP [BE-DH230FK]

The BRABER BE-DH230FK 86" Heavy-Duty Tandem Disc Harrow is built for dependable soil preparation behind compatible compact and utility tractors. Its 86-inch cutting width, notched front and rear discs, adjustable cut, disc scrapers, and heavy-duty tubular frame help prepare soil across a broad working area while supporting consistent field performance. With four gangs carrying five 18-inch discs each, the BE-DH230FK provides 20 total discs in a Category 1 and 2, three-point-hitch configuration.

Heavy-Duty Soil Preparation

The BE-DH230FK is a tandem disc harrow designed for agricultural soil-working applications. Its notched discs are arranged at both the front and rear of the implement, while scrapers help manage soil buildup during operation. The adjustable cut allows the working angle to be set for the desired soil engagement, and the heavy-duty tubular frame provides a robust foundation for the implement.

Four gangs, with five discs per gang, carry twenty total 18-inch discs across the 86-inch cutting width. Greaseable bearings support routine maintenance of the disc assemblies.

Key Features

• 86-inch cutting width
• Heavy-duty tandem disc harrow design
• Notched front and rear discs
• Disc scrapers to help manage soil buildup
• Adjustable cut for working-angle adjustment
• Heavy-duty tubular frame
• Four disc gangs
• Five discs per gang
• Twenty total discs
• 18-inch-diameter discs
• Greaseable bearings
• Three-point hitch configuration

Tractor Compatibility and Requirements

The BRABER BE-DH230FK is specified for tractors rated approximately 35-60 HP. It uses a three-point hitch and is listed for Category 1 and Category 2 tractor connections. Confirm that the tractor’s available horsepower, three-point hitch category, lifting capacity, and operating configuration are suitable for an implement weighing 1,034 lb.

Specifications

Model Identification

Product code: BE-DH230FK

The BRABER BE-DH230FK combines a wide 86-inch working width with a heavy-duty frame, adjustable cut, notched front and rear discs, and a Category 1 and 2 three-point-hitch setup for compatible 35-60 HP tractors.
