BRABER - Heavy-Duty 3-Shank 3-Point Subsoiler - 20" Working Depth - Deep Tillage & Compaction Breaking, 90-115 HP [BE-SS3HDFK]

The BRABER Heavy-Duty 3-Shank Subsoiler (BE-SS3HDFK) is a 3-point-mounted tillage implement designed for deep soil work, compaction breaking, and soil preparation. Its three shanks work to a verified depth of up to 28 inches, helping address compacted soil below the normal tillage layer. With a 60-inch working width, 21-inch tine spacing, replaceable point, shear-bolt design, and extra-thick 4 in × 4 in frame construction, this heavy-duty subsoiler is built for tractors rated from 90–115 HP.

Deep Tillage for Compaction Breaking

The BRABER BE-SS3HDFK is designed for deep soil cultivation where substantial working depth and a robust frame are required. Its three-shank configuration penetrates the soil to a verified depth of 28 inches, making the implement suitable for deep tillage and breaking up compacted layers. The 60-inch working width provides a defined pass across the field while the 21-inch tine spacing positions the shanks across the working area.

As a tractor-mounted 3-point attachment, the subsoiler is designed for use with compatible tractors in the 90–115 HP range. The implement has a Category 2 specification and is identified as compatible with Category 1 and Category 2, 3-point hitch systems.

Heavy-Duty Construction

The frame uses extra-thick 4 in × 4 in construction for demanding soil conditions. Each of the three shanks incorporates a replaceable point, supporting serviceability when the working point experiences wear. A shear-bolt design provides a specified protective feature for the shank assembly during operation.

Key Features

• Three-shank configuration for deep soil cultivation
• Verified working depth of 28 inches
• 60-inch working width
• 21-inch tine spacing
• Heavy-duty construction for deep tillage applications
• Extra-thick 4 in × 4 in frame construction
• Replaceable points
• Shear-bolt design
• 3-point hitch attachment
• Compatible with Category 1 and Category 2 hitch systems
• Designed for tractors rated 90–115 HP

Tractor Compatibility and Requirements

The BE-SS3HDFK is intended for tractors rated from 90 to 115 HP. It uses a 3-point hitch and is listed as compatible with Category 1 and Category 2 hitch systems, with the implement specified as Category 2. Confirm that the tractor’s hitch category, lifting capacity, and operating setup are suitable for the 1,147 lb implement before use.
