BRABER - GIRAFFAS160 63" 3-Point PTO Boom Mower - Internal Gearbox - Professional Offset Mowing System [MAS-GIRAFFAS160]

The BRABER MAS-GIRAFFAS160 Giraffa S 3-Point PTO Boom Flail Ditch Mower is a professional offset mowing system for tractors rated at approximately 25–35 PTO horsepower. Designed around the Maschio Giraffa boom mower configuration, it combines a 61-inch working width with hydraulic side or incline offset, allowing mowing in ditches, along slopes, beside field edges, and in other areas that are difficult to reach with a conventional rear-mounted mower. A 540 rpm PTO, Category 1 three-point hitch, side belt drive, full-width roller, safety shields, skid shoes, and standard hammer blades provide a practical setup for maintaining vegetation and cutting material up to 3/4 inch thick, subject to tractor horsepower and material density.

Professional Offset Mowing Performance

The MAS-GIRAFFAS160 is built for versatile ditch and verge maintenance where the mower head needs to work outside the tractor’s direct path. Its hydraulic system provides side or incline offset, while the mowing head can operate through an angle range of -65° to +90°. This adjustment helps position the mower for banks, inclines, drainage ditches, and roadside vegetation without requiring the tractor to travel directly over the mowing area.

The flail mowing system uses standard hammer blades, upper and lower counter-blades, and a full-width roller to support consistent cutting and ground-following performance. Front safety shields and skid shoes are included as part of the mowing head design. The side belt drive transfers power to the cutter assembly, and the supplied constant-velocity PTO shaft and standard PTO yoke connect the mower to a compatible tractor.

Key Features

• Maschio Giraffa 3-point boom mower design
• 61-inch working width
• Hydraulic side or incline offset
• Mowing angle range from -65° to +90°
• Side belt drive with 3 belts
• Full-width roller for mowing-head support
• Upper toothed counter-blades and lower counter-blades
• Skid shoes and front safety shields
• 32 standard hammer blades
• 64 optional grass knives
• Constant-velocity PTO shaft and standard PTO yoke
• Suitable for material up to 3/4 inch thick, subject to tractor horsepower and material density

Tractor Compatibility and Requirements

This mower is intended for tractors equipped with a Category 1, 3-point hitch and rated at approximately 25–35 PTO horsepower. The tractor must provide a 540 rpm PTO and have four hydraulic ports available for the mower’s hydraulic functions. Confirm that the tractor meets these hitch, PTO, horsepower, and hydraulic requirements before operation.

Specifications

The BRABER MAS-GIRAFFAS160 is suited to professional tractor operators who need offset reach and hydraulic positioning for ditch, bank, roadside, and overgrown-area mowing.
