BRABER - DL2000PR 79" 3-Point PTO Power Harrow - Packer Roller Included - Professional Seedbed Preparation [MAS-DL2000PR]

The BRABER DL2000PR 79" 3-Point PTO Power Harrow is a professional seedbed-preparation implement designed for tractors in the 60–100 HP range. Its 79-inch tilling width helps prepare a broad working pass, while the included packer roller supports a more finished seedbed and offers mechanical adjustment for setup flexibility. Built for Category 1 and Category 2 three-point hitches, the DL2000PR combines a single-speed 540 RPM gearbox, 16 blades, adjustable linkages, a rear leveling bar, and a slip clutch for dependable field operation across agricultural and land-preparation applications.

Professional Seedbed Preparation

The BRABER DL2000PR is a 3-point PTO power harrow intended for preparing soil before planting. With an 11-inch working depth and 79-inch tilling width, it is suited to tractors equipped to deliver between 60 and 100 HP. The 16-blade configuration works across the implement’s nominal working width, while the rear leveling bar helps finish the prepared surface behind the harrow.

The PR configuration includes a packer roller with mechanical roller adjusters. A central hand jack provides roller adjustment, helping the operator configure the implement for the desired operating conditions. Adjustable linkages further support installation and setup on compatible tractors.

Key Features

• 79-inch nominal tilling width for broad seedbed-preparation passes
• Packer roller included with the PR variant
• Mechanical roller adjusters for packer roller setup
• 11-inch working depth
• 16-blade configuration
• Single-speed 540 RPM gearbox
• Rear leveling bar with side jack adjustment
• Adjustable linkages
• Central hand jack for roller adjustment
• Slip clutch for PTO driveline protection
• PTO yoke included
• Category 1 and Category 2 three-point hitch compatibility

Designed for Compatible Agricultural Tractors

The DL2000PR is rated for tractors producing 60–100 HP, equivalent to 44–74 kW. It operates through a 540 RPM PTO and mounts to Category 1 or Category 2 three-point hitches. Before operation, confirm that the tractor’s hitch category, PTO speed, available power, and lifting capacity are suitable for this 1,698-pound implement.

Specifications

Included Operating Equipment

The PR model is supplied with a packer roller, mechanical roller adjusters, a PTO yoke, and a slip clutch. Its single-speed gearbox is designed for 540 RPM PTO operation. The rear leveling bar, side jack adjustment, adjustable linkages, and central hand jack provide the adjustment features needed to configure the harrow for field use.

With its professional 79-inch working width, 11-inch working depth, and packer roller included as standard for the PR configuration, the BRABER MAS-DL2000PR is equipped for substantial seedbed-preparation work behind a suitably matched 60–100 HP tractor.
