BRABER - DL1500WR 59" 3-Point PTO Power Harrow - Cage Roller Included - Professional Seedbed Preparation [MAS-DL1500WR]

The BRABER MAS-DL1500WR 3-Point PTO Power Harrow is a professional seedbed-preparation implement designed for tractors rated from 35 to 100 PTO horsepower. This WR model combines a power harrow with a cage roller to cultivate and level soil in one pass, helping prepare a consistent planting surface for agricultural and field work. It features a Category 1 and Category 2 three-point hitch, 540 RPM PTO operation, adjustable linkages, a single-speed gearbox, and practical mechanical adjustments for the roller and rear leveling bar.

Professional Soil Preparation

The MAS-DL1500WR provides a 60-inch tilling width, while its total transport width is 62 inches. The manufacturer product designation describes this model as a 59-inch power harrow. Its cage roller supports the harrow during operation and is adjustable using the central hand jack, allowing the working setup to be configured for field conditions. A rear leveling bar with side-jack adjustment helps manage the finish behind the harrow.

Power is transferred through the tractor’s 540 RPM PTO using the included PTO shaft with shear pin. The single-speed gearbox provides a straightforward mechanical drive arrangement, while adjustable linkages help connect and position the implement on compatible tractors.

Key Features

• BRABER MAS-DL1500WR power harrow with cage roller
• 60-inch manufacturer-specified tilling width
• 62-inch total width for transport and implement clearance planning
• Suitable for tractors rated from 35 to 100 PTO horsepower
• Category 1 and Category 2, three-point hitch compatibility
• 540 RPM PTO operation
• PTO shaft with shear pin
• Adjustable three-point linkages
• Single-speed gearbox
• Central hand jack for cage-roller adjustment
• Rear leveling bar with side-jack adjustment
• 12 blades

Tractor Compatibility and Requirements

This power harrow is intended for tractors with a rated output of 35 to 100 PTO horsepower, equivalent to the specified 26–74 kW power range. The implement uses a Category 1 and Category 2 three-point hitch, allowing compatibility with tractors equipped with either supported hitch category. The tractor must provide a 540 RPM PTO for the implement’s specified operating speed.

Before operation, confirm that the tractor’s three-point hitch, PTO connection, lifting capacity, and operating controls are suitable for the implement. The total implement width is 62 inches, so adequate clearance should also be confirmed for transport, field access, and storage.

Specifications
