BRABER - Category 1 3-Point Rear Ballast Box - Up to 575 lb Ballast Capacity - Compact Tractor Counterweight [BE-RWB1]

The BRABER BE-RWB1 Category 1 3-Point Rear Ballast Box is a compact tractor counterweight designed to add practical rear ballast for supported compact and subcompact tractors. With a 3.67 ft³ box volume, it accepts fill material for up to 550 lb of fill-only capacity and up to 575 lb total capacity including the box. Its Category 1 three-point hitch, quick-hitch compatibility, included lift-arm pins and top-link pin make attachment straightforward, while the sliding access door, two tool-storage sleeves and integrated 2 in square receiver add useful functionality around the property, farm or worksite.

Reliable Rear Ballast for Compact Tractors

The BE-RWB1 helps provide rear counterweight for compact and subcompact tractors when used with a compatible Category 1 three-point hitch. The box can be filled with materials such as concrete, gravel or sand, subject to the tractor’s lift capacity and operating requirements. Its compact design provides a practical way to carry ballast while retaining useful storage and receiver features for everyday tractor work.

Key Features

• Designed for Category 1 three-point hitches
• Compatible with Category 1 quick hitches
• 3.67 ft³ ballast box volume
• 550 lb maximum fill-only capacity
• 575 lb maximum capacity including the box
• Two sleeves for holding common tools
• Sliding door provides access to the box interior
• 2 in square receiver with a 5/8 in hole
• Industrial powder-coated finish
• Lift-arm pins and top-link pin included

Fill Capacity and Material Guide

The ballast box has a fill-only capacity of up to 550 lb and a total capacity of up to 575 lb including the box. Actual ballast weight depends on the selected fill material and the amount used. The supplied fill-guide weights are concrete at 150 lb/ft³, gravel at 110 lb/ft³ and sand at 100 lb/ft³. Do not exceed the ballast box capacity or the tractor manufacturer’s three-point hitch lift capacity.

Practical Worksite Features

The sliding door provides access to the interior for filling and accessing the ballast compartment. Two sleeves offer convenient storage for common tools, helping keep frequently used equipment close at hand during tractor tasks. A 2 in square receiver with a 5/8 in hole adds another useful connection point for compatible equipment or accessories.

Compatibility and Tractor Requirements

The BRABER BE-RWB1 is intended for compact and subcompact tractors equipped with a Category 1 three-point hitch. It is also Category 1 quick-hitch compatible. Confirm that the tractor can safely lift and operate the selected ballast load, as compatibility is subject to the tractor’s lift capacity.
