BRABER - 79" Hydraulic Brush Rake - Buffer System Included - Heavy-Duty Land Clearing & Debris Raking Attachment [CES-RC200SP]

BRABER CES-RC200SP 79" Orchard Brush Rake is a heavy-duty PTO-driven attachment designed for windrowing prunings and clearing orchard debris. With a 79-inch rake swath, side windrow deflector, mechanical buffer with rubber bumper, and shear pin protection, this orchard brush rake helps organize cut material into a manageable windrow while providing protection for the attachment and tractor driveline. The CES-RC200SP is built for Category 1, 3-point hitch tractors with a 540 RPM PTO and a listed 28 HP PTO rating.

Efficient Orchard Debris Management

The BRABER CES-RC200SP is intended for windrowing prunings, making it suitable for orchard maintenance and related debris-raking applications. Its 79-inch rake swath covers a broad working path, helping collect and direct pruned branches and other loose material into a defined row for subsequent removal or processing.

A side windrow deflector supports controlled material placement. Rather than leaving collected debris spread across the working area, the deflector helps guide the windrow to the side as the rake moves through the orchard. This can help maintain more orderly rows and simplify follow-up cleanup operations.

Protection and PTO Drive

The CES-RC200SP uses a 540 RPM PTO and includes a shear pin PTO yoke. Shear pin protection is designed to provide a sacrificial protection point if the rake encounters excessive resistance during operation. The mechanical buffer with rubber bumper adds another protective feature to the implement, helping manage contact and impact during use.

The verified BRABER catalogue identifies this model as a mechanical-buffer, PTO-driven orchard brush rake. The buffer system is specified as a mechanical buffer with rubber bumper; a hydraulic drive or separately included hydraulic buffer system is not part of the verified specifications.

Key Features

• 79-inch rake swath for orchard pruning and debris windrowing
• Designed for windrowing prunings
• Side windrow deflector for controlled material placement
• Mechanical buffer with rubber bumper
• Shear pin protection
• Shear pin PTO yoke
• 540 RPM PTO operation
• Category 1, 3-point hitch connection
• 664 lb implement weight
• Made in Italy

Specifications

Tractor Compatibility and Requirements

The BRABER CES-RC200SP is specified for tractors equipped with a Category 1, 3-point hitch and a 540 RPM PTO. The BRABER catalogue lists a 28 HP PTO rating and a 21 kW power rating. Confirm that the tractor meets the required hitch, PTO speed, and power specifications before operation.

Product code: CES-RC200SP
