BRABER - 6-Ton Electric Log Splitter - Compact Horizontal Splitting - Workshop & Residential Firewood Processing [LS6TE]

The BRABER LS6TE 6-Ton Electric Log Splitter is a compact horizontal splitter designed for workshop and residential firewood processing. Its 110 V electric motor delivers 6 tons of splitting force through a 2.2 in bore × 17 in stroke hydraulic cylinder, making it suitable for processing logs up to 10 in in diameter and 20-1/2 in in length. With a 14-second cycle time, automatic return valve, integrated hydraulic system, and transportation handle, the LS6TE provides a practical solution for routine firewood preparation where electric power is available.

Efficient Electric Firewood Processing

The BRABER LS6TE uses a 1300 W electric motor operating at 3400 RPM to power its hydraulic splitting system. The 6-ton splitting force is supported by a maximum hydraulic pressure of 2700 PSI, providing the power required for the listed log capacity. Its 110 V, 60 Hz electrical supply is suited to compatible electrical installations, while the integrated hydraulic system eliminates the need for a separate hydraulic power source.

Designed for horizontal log splitting, the LS6TE offers a compact format for workshop and residential use. The automatic return valve helps reset the splitter after each cycle, and the 14-second cycle time supports consistent operation during firewood-processing tasks.

Key Features

• 6-ton splitting force for residential and workshop firewood processing
• 110 V, 60 Hz electric power supply
• 1300 W power output
• 12 A rated current
• 3400 RPM electric motor speed
• 2.2 in bore × 17 in stroke hydraulic cylinder
• 2700 PSI maximum hydraulic pressure
• 14-second cycle time
• Automatic return through the standard valve type
• Supports logs up to 10 in in diameter and 20-1/2 in in length
• Transportation handle for moving the splitter
• Optional 4-way integrated splitting wedge

Hydraulic System and Operation

The LS6TE features an integrated hydraulic system with a 3.8 L oil capacity and a maximum pressure of 2700 PSI. Its 2.2 in bore × 17 in stroke cylinder provides the hydraulic movement required for the listed 6-ton splitting force. The standard automatic return valve helps return the splitting mechanism after operation, supporting a repeatable workflow from one log to the next.

Log Capacity

The manufacturer lists the LS6TE for logs up to 10 in in diameter and 20-1/2 in in length. These are the maximum listed splitting dimensions for the model. Logs should be prepared within these dimensions for operation according to the stated product specifications.

Portability and Optional Splitting Configuration

A transportation handle is included as part of the listed transport equipment, helping with movement of the splitter between suitable work areas. For users seeking to divide logs into multiple sections in a single pass, the manufacturer lists an optional 4-way integrated splitting wedge. This wedge is an option rather than a standard listed feature.
