BRABER - 37-Ton Professional Towable Log Splitter - PowerEase Engine - Heavy-Duty Horizontal/Vertical Splitting [BE-LS37DR]

The BRABER BE-LS37DR 37-Ton Deluxe Professional Towable Log Splitter is built for demanding firewood processing on farms, acreages, and serious home properties. Its PowerEase 212 cc / 7 HP gasoline engine drives a 16 GPM hydraulic system delivering up to 37 tons of splitting force, while the full-beam construction and 5 in x 24 in hydraulic cylinder provide a heavy-duty foundation for handling logs up to 24 inches long and 14 inches in diameter. Use it horizontally for convenient loading or vertically when working with larger, heavier rounds. With a 3-position control, automatic ram return, integrated log dislodger, and DOT-rated towing equipment, the BE-LS37DR is designed to help you split more wood efficiently and move the machine around your property when needed.

Professional Splitting Performance

The 37-ton splitting force is suited to serious firewood workloads, with an 11-second forward cycle and 9.5-second reverse cycle to support productive operation. The 7-inch wedge height and over-top engineered log dislodger help manage split material during repeated use. A 3-position control with automatic ram return simplifies the splitting cycle, allowing the ram to return automatically after the log has been split.

Horizontal and Vertical Operation

The BE-LS37DR supports both horizontal and vertical splitting positions. Horizontal operation provides a practical setup for loading suitable logs, while vertical operation can be used when handling larger or heavier rounds that are difficult to lift onto the beam. This two-position design gives operators flexibility for different log sizes and working conditions.

Heavy-Duty Hydraulic and Frame Design

A full-beam construction supports the splitter’s professional-duty design. The integrated hydraulic system includes a 16 GPM pump, maximum hydraulic pressure of 3500 PSI, a 20.3 L / 5.4 gal hydraulic reservoir, and a 6.4 L / 1.7 gal cylinder capacity. The 5 in x 24 in hydraulic cylinder is matched to the machine’s 37-ton splitting force and 24-inch maximum log-length capacity.

Key Features

• 37-ton professional splitting force
• PowerEase 212 cc / 7 HP gasoline engine
• Horizontal and vertical splitting positions
• 24-inch maximum log length
• 14-inch maximum splitting diameter
• 3-position control with automatic ram return
• Full-beam construction
• Over-top engineered log dislodger
• 16 GPM hydraulic pump with up to 3500 PSI pressure
• DOT tires rated for towing speeds up to 45 mph / 72 km/h
• LED towing lights, wheel fenders, and upgraded wheel jack
• Heavy-duty tapered wheel bearings
• Safety chains and spring release pin
• Optional LS4CW 4-way cross wedge available for compatibility with BE-LS37DR

Towable Design and Transport Equipment

The BE-LS37DR is equipped for towing with a 2-inch ball coupler, DOT tires, LED towing lights, wheel fenders, heavy-duty tapered wheel bearings, and an upgraded wheel jack. Safety chains and a spring release pin are also included as part of the transport safety equipment. The specified maximum towing speed is 45 mph / 72 km/h.

Compatibility

The optional BRABER LS4CW 4-way cross wedge is listed as compatible with the BE-LS37DR. The accessory provides an optional configuration for users seeking to process multiple splits from a single log cycle.
