BRABER - 37-Ton Professional Towable Log Splitter - Honda Engine - Heavy-Duty Horizontal/Vertical Splitting [BE-LS37DH9]

BRABER BE-LS37DH 37-Ton Professional Towable Log Splitter is a deluxe commercial-grade gas log splitter designed for demanding towable log-splitting applications. Powered by a Honda GX390 389 cc OHV engine, it combines 37 tons of splitting force with a 16 GPM two-stage Hi-Lo hydraulic pump for strong, efficient performance. Full-beam construction, an over-top engineered log dislodger, automatic ram return, and a road-ready towing package make this splitter well suited to processing logs up to 24 inches in length and 14 inches in diameter for commercial, property-maintenance, and firewood-processing work.

Professional Splitting Performance

The BRABER BE-LS37DH is built around a Honda GX390 engine rated at 13 HP. Its self-contained, engine-driven hydraulic system uses a 16 GPM two-stage Hi-Lo pump to deliver the hydraulic performance required for heavy-duty log splitting. The 3-position control system includes automatic ram return, helping streamline repeated splitting cycles with an 11-second forward cycle and a 9.5-second reverse cycle.

With a rated splitting force of 37 tons, the BE-LS37DH is designed for substantial logs within its stated capacity. The full-beam frame provides the foundation for the splitter’s commercial design, while the over-top engineered log dislodger helps remove logs from the beam after splitting.

Built for Towing and Transport

This towable gas log splitter includes a road towing package intended for transport between work areas. DOT-rated tires support a maximum towing speed of 72 km/h (45 mph), and the package includes LED towing lights, wheel fenders, safety chains, and a spring release pin. An upgraded wheel jack and heavy-duty tapered wheel bearings further support the machine’s towable configuration.

Key Features

• 37-ton splitting force for demanding log-splitting applications
• Honda GX390 389 cc OHV engine rated at 13 HP
• 16 GPM two-stage Hi-Lo hydraulic pump
• 11-second forward and 9.5-second reverse cycle times
• 3-position control system with automatic ram return
• Full-beam construction for a heavy-duty commercial design
• Over-top engineered log dislodger
• Log capacity of up to 24 inches in length and 14 inches in diameter
• DOT-rated tires with a maximum towing speed of 72 km/h (45 mph)
• LED towing lights and included wheel fenders
• Heavy-duty tapered wheel bearings
• Safety chains and spring release pin included
• Upgraded wheel jack

Specifications

Hydraulic System

The splitter uses a self-contained Honda GX390 engine-driven hydraulic system, eliminating the need for a separate tractor power source. The hydraulic system is specified with a 16 GPM two-stage Hi-Lo pump.

Towing Package

The BE-LS37DH is equipped for towable log-splitting applications with DOT-rated tires, LED towing lights, wheel fenders, an upgraded wheel jack, heavy-duty tapered wheel bearings, safety chains, and a spring release pin. Always observe the specified maximum towing speed of 72 km/h (45 mph).
