BRABER - 37-Ton Professional Towable Log Splitter - Honda Engine - Heavy-Duty Horizontal/Vertical Splitting [BE-LS37DH]

The BRABER BE-LS37DH Professional 37-Ton Towable Log Splitter combines a Honda GX390 gasoline engine with a heavy-duty hydraulic system for demanding firewood processing and property-maintenance work. Its 37-ton splitting force, 24-inch maximum log length, and 14-inch splitting diameter provide substantial capacity for large logs, while horizontal and vertical operating positions allow you to choose the most practical setup for each job. Designed for towable use, the BE-LS37DH includes a 2-inch ball coupler, LED towing lights, DOT tires, wheel fenders, safety chains, and an upgraded wheel jack for convenient movement between work areas.

Professional Splitting Performance

The BE-LS37DH is powered by a Honda GX390 engine rated at 389 cc / 13 HP. Its integrated gasoline-engine hydraulic system uses a 16 GPM pump and delivers up to 3,500 PSI of hydraulic pressure. The 5-inch x 24-inch hydraulic cylinder provides the force needed for the splitter’s 37-ton rating, while the 11-second forward cycle and 9.5-second reverse cycle support productive operation.

A 3-position control with automatic ram return helps streamline repeated splitting cycles. The over-top engineered log dislodger is designed to help remove split or stubborn logs from the working area, and the full-beam construction supports the machine’s heavy-duty design.

Horizontal and Vertical Operation

The BRABER BE-LS37DH can be used in both horizontal and vertical splitting positions. Horizontal operation is suitable for handling logs on the beam, while vertical operation can help reduce the need to lift larger rounds onto the machine. This flexibility makes the splitter adaptable to different log sizes, worksite conditions, and operator preferences.

Key Features

• 37-ton splitting force for demanding log-splitting applications
• Honda GX390 gasoline engine, 389 cc / 13 HP
• Maximum log length of 24 inches
• Splitting diameter of up to 14 inches
• Horizontal and vertical splitting positions
• 11-second forward cycle and 9.5-second reverse cycle
• 16 GPM hydraulic pump with 3,500 PSI maximum pressure
• 3-position control with automatic ram return
• Over-top engineered log dislodger
• Full-beam construction
• LED towing lights and DOT tires rated up to 72 km/h / 45 mph
• Wheel fenders, safety chains, and upgraded wheel jack
• Heavy-duty tapered wheel bearings
• 2-inch ball coupler for towing
• Compatible with the optional BRABER LS4CW 4-way cross wedge

Built for Towable Use

With a 2-inch ball coupler and towing-focused equipment, the BE-LS37DH is configured for transport between splitting locations. LED towing lights, DOT tires, wheel fenders, safety chains, an upgraded wheel jack, and heavy-duty tapered wheel bearings are included as part of the towable design. The tires are rated for speeds up to 72 km/h / 45 mph.

Specifications

Compatible Attachment

The BRABER BE-LS37DH is compatible with the optional BRABER LS4CW 4-way cross wedge, which is listed by BRABER as an available compatible attachment.
