BRABER - 28-Ton Deluxe Towable Log Splitter - PowerEase Engine - Horizontal/Vertical Firewood Splitting - Firewood Processing Equipment [BE-LS28DR]

The BRABER BE-LS28DR 28-Ton Deluxe Towable Log Splitter is a Professional-series firewood processing machine built for demanding residential, property-maintenance, and firewood-preparation work. Its PowerEase 212 cc / 7 HP engine drives a 13 GPM hydraulic system capable of delivering 28 tons of splitting force, while the full-beam construction and over-top engineered log dislodger support efficient handling during repeated splitting. Configure the splitter for either horizontal or vertical operation, depending on the size and handling requirements of the log. When the work area changes, the towable design includes a 2 in ball coupler, DOT tires, LED towing lights, safety chains, wheel fenders, and an upgraded wheel jack for transport.

Key Features

• 28-ton splitting force: Designed to process firewood logs up to 24 in long and 14 in in splitting diameter.
• PowerEase engine: Powered by a PowerEase 212 cc / 7 HP engine.
• Horizontal and vertical operation: Provides two splitting positions for different log-handling needs.
• Efficient hydraulic system: Features a 13 GPM hydraulic pump and maximum hydraulic pressure of 3,450 PSI.
• Fast cycle performance: The ram cycle is rated at 11 seconds forward and 9.5 seconds reverse.
• Three-position control: Includes automatic ram return for convenient operation.
• Full-beam construction: Built with an over-top engineered log dislodger to help remove split or obstructed logs.
• Towable configuration: Includes a 2 in ball coupler, DOT tires, maximum towing speed of 72 km/h / 45 mph, and transport safety equipment.
• Transport equipment: Includes LED towing lights, wheel fenders, heavy-duty tapered wheel bearings, an upgraded wheel jack, safety chains, and a spring release pin.

Built for Flexible Firewood Processing

The BE-LS28DR is configured for both horizontal and vertical splitting positions, allowing the operator to select the setup suited to the job. Horizontal operation provides a practical arrangement for handling manageable logs, while vertical operation can help position larger rounds without requiring the log to be lifted onto the beam. The 24 in maximum log length and 14 in splitting diameter provide a defined working range for firewood preparation.

A 3-position control with automatic ram return supports a straightforward splitting sequence. The 4.5 in x 24 in hydraulic cylinder works with the 13 GPM pump and 18.9 L / 5 gal hydraulic reservoir to deliver the splitter’s rated performance. The cylinder capacity is 5.4 L / 1.4 gal.

Heavy-Duty Frame and Towing Equipment

Full-beam construction provides the foundation for this towable log splitter, while the over-top engineered log dislodger is designed to assist with clearing logs from the splitting area. For relocation between work sites, the BRABER BE-LS28DR uses a 2 in ball coupler and DOT tires rated for towing speeds up to 72 km/h / 45 mph. LED towing lights, wheel fenders, safety chains, heavy-duty tapered wheel bearings, an upgraded wheel jack, and a spring release pin are included as part of its transport equipment.

Specifications

Compatible Option

The optional LS4CW 4-way cross wedge attachment is listed as compatible with the BRABER BE-LS28DR.
