BRABER - 28-Ton Deluxe Towable Log Splitter - Honda Engine - Horizontal/Vertical Firewood Splitting - Firewood Processing Equipment [BE-LS28DH]

The BRABER BE-LS28DH 28-Ton Deluxe Towable Log Splitter is a professional-grade, gas-powered hydraulic splitter designed for efficient firewood processing in residential, property-maintenance, and demanding outdoor applications. Powered by a dependable Honda GX200 196 cc, 6.5 HP engine, it delivers up to 28 tons of splitting force through a 13 GPM two-stage Hi-Lo hydraulic pump. Its horizontal and vertical operating positions provide flexibility when handling different log sizes, while the full-beam frame, automatic ram return, engineered log dislodger, and road-ready towing package support productive and convenient use around the property or between work locations.

Powerful Hydraulic Firewood Processing

The BE-LS28DH is equipped to process logs up to 24 inches long, with a stated splitting diameter of 14 inches and a 7-inch wedge height. Its 13 GPM two-stage hydraulic pump combines efficient operation with substantial splitting capability, supported by a maximum hydraulic pressure of 3,450 PSI. The hydraulic system uses a 4.5-inch by 24-inch cylinder, an 18.9 L / 5 gal hydraulic reservoir, and a 5.4 L / 1.4 gal cylinder capacity.

Horizontal and Vertical Splitting Positions

The splitter can be operated in both horizontal and vertical positions. This flexibility allows the machine to be configured for the intended log-handling task, including applications where lifting larger or heavier rounds onto a horizontal work position may be less convenient. A three-position control system with automatic ram return helps streamline the splitting cycle, providing an 11-second forward cycle and a 9.5-second reverse cycle.

Built for Towing and Transport

The BRABER BE-LS28DH is built in a towable, road-ready configuration. Its transport package includes DOT-rated tires, LED towing lights, wheel fenders, heavy-duty tapered wheel bearings, an upgraded wheel jack, and a 2-inch ball coupler. Safety chains and a spring-release pin are included as transport safety equipment. The manufacturer specifies a maximum towing speed of 72 km/h / 45 mph. Shipping weight is 624 lb.

Key Features

• 28-ton hydraulic splitting force
• Honda GX200 OHV engine with 196 cc displacement and 6.5 HP rating
• Horizontal and vertical operating positions
• 13 GPM two-stage Hi-Lo hydraulic pump
• Maximum hydraulic pressure of 3,450 PSI
• Three-position control with automatic ram return
• 11-second forward cycle and 9.5-second reverse cycle
• Full-beam construction
• Over-top engineered log dislodger
• Maximum log length of 24 inches
• Stated splitting diameter of 14 inches
• DOT-rated tires and road-towing package
• LED towing lights and wheel fenders
• Heavy-duty tapered wheel bearings
• Upgraded wheel jack and 2-inch ball coupler
• Safety chains and spring-release pin

Specifications
