HLA Attachments - 72" 4-in-1 Skid Steer Bucket [LA-SBFNO72BO500]

HLA Attachments SBFNO72 72-inch 4-in-1 Skid Steer Bucket is a hydraulically operated attachment designed for compatible skid-steer loaders. Its 4-in-1 bucket configuration uses included 2-1/2 x 8-inch hydraulic cylinders, combining a 72-inch inside width with robust material thicknesses for demanding bucket work. With an 11.6-cubic-foot struck capacity, 15.1-cubic-foot SAE heaped capacity, and preparation for a standard bolt-on cutting edge, this bucket provides a practical combination of capacity, durability, and hydraulic functionality.

Hydraulic 4-in-1 Bucket Design

The SBFNO72 features a hydraulic 4-in-1 design operated by 2-1/2 x 8-inch cylinders. A hydraulic supply from the skid-steer loader is required to operate the cylinders. This design gives operators the functionality of a hydraulically actuated bucket in a 72-inch inside-width format.

The manufacturer does not publish specific hydraulic flow or pressure requirements for this model. An optional HLA Attachments HK90 hose kit is listed for the bucket and includes 90-inch hoses with flat-faced couplers.

Built with Heavy Material Thicknesses

The bucket is manufactured with 1/4-inch main bucket material, supported by 3/8-inch end plates. The clam-floor bottom is also constructed from 3/8-inch material. These specified material thicknesses provide a substantial structure throughout key bucket and clam components.

For servicing or configuring the working edge, the bucket is drilled for a standard bolt-on cutting edge. This preparation allows an appropriate standard bolt-on cutting edge to be fitted without requiring the bucket edge to be newly drilled.

Capacity and Dimensions

HLA’s SBFNO72 has a 72-inch inside width and a calculated outside width of 74 inches. Its bucket body measures 29 inches deep and 20 inches high. Capacity is rated at 11.6 cubic feet struck and 15.1 cubic feet SAE heaped, providing clearly defined capacity figures for equipment selection and job planning.

The bucket has an approximate weight of 1,027 pounds. Operators should account for the attachment weight, its contents, and the operating limits of the skid-steer loader when determining suitability.

Key Features

• Hydraulic 4-in-1 skid-steer bucket design
• 72-inch inside width
• 74-inch calculated outside width
• Includes 2-1/2 x 8-inch hydraulic cylinders
• 11.6-cubic-foot struck capacity
• 15.1-cubic-foot SAE heaped capacity
• 1/4-inch main bucket material
• 3/8-inch end plates
• 3/8-inch clam-floor bottom
• Drilled for a standard bolt-on cutting edge
• Approximate attachment weight of 1,027 pounds

Compatibility

This attachment is designed for use with skid-steer loaders. Before fitting, confirm that the loader can safely handle the bucket’s approximate 1,027-pound weight together with the intended load. Hydraulic capability is required to operate the included cylinders.

Hydraulic Requirements

A hydraulic supply is required for the bucket’s included 2-1/2 x 8-inch cylinders. Hydraulic flow and pressure requirements are not published for this model. The optional HK90 hose kit, featuring 90-inch hoses and flat-faced couplers, is listed separately by HLA Attachments.
