HLA Attachments - Three Point Hitch Skid Steer PTO Adapter High Flow - Skid Steer and Tractor Adapter [LA-PTOHF]

HLA Attachments PTOHF High-Flow Three-Point Hitch Skid-Steer PTO Adapter adds a hydraulic PTO and three-point hitch to a compatible skid-steer loader, allowing the carrier to operate a range of PTO-driven three-point implements. Designed for skid steers equipped with 30–40 GPM high-flow auxiliary hydraulics, this adapter delivers 40–45 HP of hydraulic PTO power. Its Category 1 and Category 2 compatibility makes it suitable for implements such as brush cutters and snow blowers, while the included high-flow hose and coupler kit helps provide the hydraulic connection required for operation.

Turn a High-Flow Skid Steer into a Versatile Implement Carrier

The PTOHF combines a hydraulic PTO with a three-point hitch in a single skid-steer-mounted adapter. This configuration expands the types of equipment that can be used with an adequately equipped skid steer, providing a practical connection for compatible three-point, PTO-driven implements.

An adjustable top link is included to help accommodate Category 1 and Category 2 implement configurations. The adapter is rated for a 4,000 lb capacity and also incorporates a 2-inch receiver, adding another useful connection point to the attachment.

Key Features

• Adds a hydraulic PTO and three-point hitch to a skid-steer loader
• Designed for 30–40 GPM high-flow auxiliary hydraulics
• Provides 40–45 HP of hydraulic PTO power
• Compatible with Category 1 and Category 2 three-point implements
• Adjustable top link included
• High-flow hose and coupler kit included
• Rated for a 4,000 lb capacity
• Integrated 2-inch receiver
• Approximate attachment weight of 440 lb

Implement Compatibility

The HLA Attachments PTOHF is intended for use with Category 1 and Category 2 three-point implements that can be powered by its hydraulic PTO system. Supported applications include hydraulic PTO-driven equipment such as brush cutters and snow blowers.

Implement selection should account for the adapter’s 40–45 HP hydraulic PTO rating, 4,000 lb capacity, and hitch compatibility. The implement must also be suitable for the operating characteristics of the adapter and the available hydraulic output of the skid-steer loader.

Skid-Steer Hydraulic Requirements

This is the high-flow PTO adapter model and requires a skid-steer loader with adequate high-flow auxiliary hydraulics. The specified hydraulic flow requirement is 30–40 GPM. A high-flow hose and coupler kit is supplied with the adapter.

Before use, confirm that the skid steer can provide hydraulic flow within the required range and is suitable for the combined weight and operating demands of the adapter and selected implement.

Specifications
