WALLENSTEIN 25 Ton, Horizontal, Tractor

The Wallenstein WX330 25 Ton Horizontal Tractor Log Splitter is a tractor-mounted hydraulic log splitter designed for efficient firewood processing with compact tractors equipped with a Category I 3-point hitch. Delivering 25 tons of split force and a 48-inch split opening, the WX330 handles logs up to 48 inches long in a horizontal orientation. Its wide wedge helps the wood block pop early in the split, while wide log shelves provide support during operation. Direct pressure, hands-free return, and included hydraulic hoses and couplers help streamline splitting work in residential, farm, acreage, and property-maintenance applications.

Key Features

• 25-ton split force: Provides substantial hydraulic force for processing firewood.
• 48-inch split opening: Designed for logs up to 48 inches in length.
• Horizontal orientation: Supports horizontal log-splitting operation from a tractor-mounted position.
• Wide wedge: Helps the wood block pop early in the split.
• Wide log shelves: Provide support for logs during splitting.
• Direct pressure: Applies hydraulic pressure directly during the splitting cycle.
• Hands-free return: Allows the splitter to return without requiring continuous manual operation.
• Hydraulic equipment included: Supplied with hydraulic hoses and couplers.

Product Overview

The WX330 is built for tractor-powered log splitting where hydraulic power and three-point-hitch mounting are preferred. Its horizontal configuration provides a practical working position for processing logs, while the 10-inch wedge height and 4.5-inch cylinder diameter support the unit’s 25-ton rated split force. The splitter’s average cycle time is 15.24 seconds, with a full cycle time of 30.48 seconds; actual cycle times depend on the hydraulic flow supplied by the tractor.

With an overall length of 120 inches and a transport width of 30 inches, the WX330 is sized for tractor-mounted use while weighing 425 pounds. The mounting system is compatible with Category I three-point hitches, iMatch™, and Quick Hitch systems, making it suitable for compatible compact tractors and hitch setups.

Specifications

Compatibility

The Wallenstein WX330 is compatible with compact tractors equipped with a Category I 3-point hitch. It is also compatible with iMatch™ and Quick Hitch systems.

Tractor Requirements

The recommended tractor hydraulic flow for the WX330 is 13 gpm (50 lpm). Cycle times depend on the hydraulic flow available from the tractor. Confirm that the tractor has a compatible Category I three-point hitch or compatible iMatch™ or Quick Hitch system before use.
