HLA Attachments - 54" Concrete Hopper Bucket - Concrete Handling Attachment [LA-CHB54BO500]

SKU LA-CHB54BO500

Starting at: Starting at $3,805.⁰⁰

Starting at: Starting at $3,805.⁰⁰

Add your items to the Cart to begin to build and price your package.

When you're ready to take the next step, please reach out to us for a quote, or complete the checkout process to reserve your items in store. (The online checkout just emails us a copy of the items you are interested in, we then reach out to you to confirm everything.)

Showing pricing online is difficult, here's why:
*Pricing shown at MSRP and may not include available Timberstar Tractor or Manufacturer discounts.
*Finance rates, payment calculations, whether or not you need a down payment, all available through our sales staff.
*Online pricing does not include freight, assembly, finance, delivery, or pdi fees.
*Our manufacturer's pricing is subject to change without notice.
*Manufacturer sales promotions valid unitl the end of the month they were issued in.
*Price match available for many brands we carry.

Description

HLA Attachments CHB54BO500 54-Inch Concrete Hopper Bucket is a concrete-handling attachment designed to move and place up to 15 cu. ft. of concrete while reducing manual handling and eliminating the need for wheelbarrows. Its compact hopper, hydraulically controlled discharge gate, and 30-inch swinging chute make it particularly useful for placing concrete in tight working areas. Configured with the BO500 skid-steer-style quick-attach mount, it is easy to attach to most skid-steer loaders equipped with a compatible carrier.

Efficient Concrete Handling

The CHB54BO500 combines a 54-inch inside width with a 14.5-cu.-ft. struck capacity and an advertised concrete capacity of up to 15 cu. ft. It allows concrete to be transported directly from the mixing or delivery point to the placement area, helping reduce the time and labour associated with moving material by wheelbarrow.

The hopper measures 55 inches wide, 25 inches long, and 23 inches high externally. These compact dimensions help the attachment work effectively where access is limited. With an approximate attachment weight of 490 lb, it provides substantial concrete-carrying capacity in a manageable skid-steer-mounted package.

Controlled Concrete Placement

A hydraulically controlled discharge gate gives the operator control over the release of concrete from the loader seat. The discharge opening measures 13 inches by 5 inches, directing material into the 30-inch swinging chute. The chute helps guide concrete toward the required placement point and is especially useful when working around forms or in confined spaces.

Auxiliary hydraulics are required to operate the discharge gate. Optional hydraulic hose kits are available with flat-faced couplers, including a standard configuration and an alternative with 90-degree couplers. An optional spring hose-mount kit is also available to support hose management.

Key Features

Hauls up to 15 cu. ft. of concrete
14.5-cu.-ft. struck hopper capacity
54-inch inside hopper width
Designed to reduce manual concrete handling and eliminate wheelbarrow use
Compact design suited to tight working areas
30-inch swinging discharge chute for directed placement
13-inch by 5-inch discharge opening
Hydraulically controlled discharge gate
BO500 skid-steer-style quick-attach mount
Easy attachment and operation
Optional hydraulic hose and hose-mount kits available

Compatibility

The CHB54BO500 is configured with an HLA Attachments BO500 skid-steer-style quick-attach mount. It is compatible with most skid-steer loaders and BO500 skid-steer-style quick-attach carriers. Confirm that the loader’s carrier, lift capacity, and hydraulic connections are suitable for the attachment and intended load before use.

Hydraulic Requirements

The discharge gate requires auxiliary hydraulics. Hydraulic flow and pressure requirements are not published. Hydraulic hose kits with flat-faced couplers are optional and can be selected to suit the loader connection arrangement.

Specifications

Brand	HLA Attachments
Model	CHB54BO500
Product type	Concrete hopper bucket / concrete-handling attachment
Model configuration	CHB54 base bucket with BO500 skid-steer-style quick-attach mount
Inside width	54 in.
Outside hopper dimensions	55 in. wide × 25 in. long × 23 in. high
Struck capacity	14.5 cu. ft.
Advertised concrete capacity	Up to 15 cu. ft.
Approximate weight	490 lb
Discharge chute	30 in. swinging chute
Discharge opening	13 in. × 5 in.
Gate operation	Hydraulic discharge-gate control
Quick attach	BO500 skid-steer-style quick attach
