Description

HLA Attachments MFE48BO500 48-Inch Manure Fork is a loader-mounted material-handling attachment designed for manure and livestock applications. This configuration combines the 48-inch MFE48 base fork with HLA’s BO500 universal skid-steer-style quick-attach mount. Seven cranked Kverneland tines provide superior penetration, while 7.5-inch tine spacing supports effective handling of manure and other livestock materials. A flat upper frame also serves as a convenient level indicator, helping the operator judge the fork’s position during use.

Designed for Manure and Livestock Handling

The MFE48BO500 uses seven Conus I cranked Kverneland tines, each with a nominal length of 35 inches and a usable tine length of 31 inches. The cranked profile and generous working length allow the fork to penetrate and carry material while providing ample tine engagement.

At 48 inches wide, this manure fork offers a compact working width for handling material in livestock areas and other farm environments. The seven tines are arranged on 7.5-inch centers for consistent coverage across the fork. The approximate base-fork weight is 350 lb.

BO500 Quick-Attach Mount

This model is supplied in the BO500 mount configuration. The BO500 is HLA’s universal skid-steer-style loader mount and uses a quick-attach connection. It is intended for compatible skid-steer-style loader quick-attach carriers, allowing the attachment to be connected and removed without a pin-on mounting arrangement.

Key Features

  • 48-inch manure fork for farm and livestock material handling
  • Seven cranked Kverneland tines for superior penetration
  • Conus I tine design
  • 35-inch nominal tine length
  • 31-inch usable tine length
  • 7.5-inch spacing between tine centers
  • Flat top acts as a level indicator during operation
  • BO500 universal skid-steer-style loader mount
  • Quick-attach mount connection
  • Approximate base-fork weight of 350 lb

Compatibility

The HLA MFE48BO500 is compatible with skid-steer-style loader quick-attach carriers that accept the HLA BO500 universal mount. Confirm that the loader carrier uses the appropriate skid-steer-style quick-attach interface before installation.

Specifications

Brand HLA Attachments
Model MFE48BO500
Product code LA-MFE48BO500
Product type Manure fork with cranked Kverneland tines
Base fork model MFE48
Mount option code BO500
Working width 48 in
Number of tines 7
Tine type Cranked Kverneland, Conus I
Nominal tine length 35 in
Usable tine length 31 in
Tine centers 7.5 in
Approximate base-fork weight 350 lb
Mount configuration Universal skid-steer-style loader mount
Mount connection Quick attach
