HLA Attachments - 103" Stone Fork Heavy Duty with Split Grapple - Stone and Debris Handling [LA-SFRHDB103BO500]

HLA Attachments SFRHDB103 Heavy-Duty 103-Inch Stone Fork with Split Grapple is built for demanding rock, brush and debris cleanup with loaders and skid steers equipped with a BO500 skid-steer-style quick-attach carrier. Combining retainer-style stone-fork tines with two independent hydraulic grapples, this attachment provides the holding capability needed to control awkward, abrasive loads. Its heavy-duty construction is rated for loads up to 9,500 lb, making it a robust material-handling solution for property cleanup, construction sites, landscaping, agricultural operations and other intensive applications.

Heavy-Duty Stone and Debris Handling

The SFRHDB103 has a 103-inch working width for handling substantial volumes of material. Its retainer-style tine configuration is designed for stone-fork applications, while the split grapple helps secure rocks, brush and mixed debris during pickup and transport. This combination provides a practical way to manage bulky material that may be difficult to control with a conventional bucket or non-grapple attachment.

Heavy-duty construction supports a rated capacity of up to 9,500 lb. The attachment weighs approximately 2,295 lb and measures 30 inches high by 40 inches deep. These dimensions and its substantial build are intended for demanding applications involving abrasive material and irregular loads.

Two Independent Grapple Sections

Instead of a single grapple across the full width, this model uses two independent grapple sections. The split configuration is especially useful when working with uneven, irregularly shaped or mixed loads. Two 2-1/2-inch by 8-inch hydraulic cylinders operate the grapple system, providing hydraulic clamping for better material retention while moving brush, rocks and debris.

An auxiliary hydraulic circuit is required to operate the split grapple. Hydraulic flow and pressure requirements are not specified, so the carrier’s hydraulic suitability should be confirmed before installation.

Key Features

• 103-inch heavy-duty stone fork for rock, brush and debris handling
• Rated for loads up to 9,500 lb
• Two independent grapple sections for securing awkward and irregular material
• Two 2-1/2-inch by 8-inch hydraulic cylinders
• Retainer-style stone-fork tines
• Designed for brush and rock cleanup
• Built for awkward, abrasive loads
• BO500 skid-steer-style quick-attach mounting interface
• Approximately 2,295 lb attachment weight

Compatibility

This attachment is configured with the HLA Attachments BO500 mounting code and a skid-steer-style quick-attach interface. It is compatible with loaders and skid steers that use a BO500 skid-steer-style quick-attach carrier. Carrier capacity, mounting fit and hydraulic compatibility should be verified for the complete loader or skid-steer configuration.

Carrier and Hydraulic Requirements

• Carrier interface: BO500 skid-steer-style quick attach
• Hydraulics: Auxiliary hydraulic circuit required for grapple operation
• Grapple cylinders: Two 2-1/2-inch by 8-inch cylinders
• Hydraulic flow and pressure: Not specified
