HLA Attachments - Deep Less Attach 48" 72" - Low-Profile Skid Steer Attachment [LA-SBLPC4872BO500]

HLA Attachments SBLPC4872BO500 Heavy-Duty Conveyor Cleanout Bucket is a purpose-built skid-steer attachment designed to provide access beneath aggregate conveyors and assist with cleanout work in confined, low-clearance areas. Its 48-inch inside width, extended 72-inch floor, and 6-inch-tall side plates create a long, open bucket profile suited to reaching beneath conveyor structures. Heavy-duty construction includes 1/4-inch bucket material, 1/4-inch side plates, a reinforced top lip, and a substantial 3/4 x 6-inch bevelled cutting edge. This configuration is supplied with HLA’s BO500 skid-steer quick-attach mount.

Designed for Conveyor Cleanout

The SBLPC4872 is identified by HLA Attachments as a heavy-duty conveyor cleanout bucket. Its distinctive dimensions support a specialized role: the bucket combines a narrow 48-inch inside width with a 72-inch floor length, allowing it to reach farther beneath aggregate conveyor systems than a conventional general-purpose bucket. The 6-inch side plates help maintain access beneath low structures while still providing material containment along the bucket floor.

A 19-inch-high back helps retain collected material, while the reinforced top lip adds strength to the bucket structure. The result is a practical attachment for operators who need to retrieve spilled or accumulated aggregate from areas that can be difficult to reach with a standard bucket profile.

Heavy-Duty Bucket Construction

Both the main bucket material and the side plates are manufactured from 1/4-inch material. At the working edge, the bucket uses a 3/4 x 6-inch bevelled cutting edge for robust engagement with material. It is also drilled to accept a standard bolt-on cutting edge, providing preparation for an additional replaceable edge where required.

The published approximate weight of 695 lb applies to the SBLPC4872 base bucket less attachment or mount. It does not represent a verified complete operating weight for the bucket with the BO500 mounting assembly installed.

Key Features

• Heavy-duty conveyor cleanout bucket from HLA Attachments
• 48-inch inside width for access in confined conveyor cleanout areas
• 72-inch floor length for extended reach beneath aggregate conveyors
• Low 6-inch side plates designed to provide access beneath conveyor structures
• 19-inch-high back for material retention
• 1/4-inch bucket material
• 1/4-inch side-plate construction
• 3/4 x 6-inch bevelled cutting edge
• Drilled for a standard bolt-on cutting edge
• Reinforced top lip for added structural strength
• BO500 skid-steer quick-attach mount

Compatibility

This bucket is fitted with HLA mounting code BO500, a skid-steer quick-attach mount. It is intended for skid-steer quick-attach carriers compatible with the HLA BO500 mounting configuration. Confirm the carrier’s attachment interface and operating capacity before use.
