HLA Attachments - Deep Less Attach 36" 60" - Low-Profile Skid Steer Attachment [LA-SBLPC3660BO500]

HLA Attachments SBLPC3660BO500 Heavy-Duty Conveyor Cleanout Bucket is purpose-built for removing accumulated material from beneath aggregate conveyors. Its narrow 36-inch inside width, low 6-inch side plates, and extended 60-inch floor help the bucket reach into confined areas where conventional bucket profiles may have limited access. Constructed with 1/4-inch bucket material and side plates, a reinforced top lip, and a substantial 3/4 x 6-inch beveled cutting edge, this specialized bucket combines extended reach with the durability required for demanding conveyor cleanout work.

Designed for Conveyor Cleanout

HLA Attachments catalogues the SBLPC3660 as a heavy-duty Conveyor Cleanout Bucket. Unlike a standard material bucket, it has a long, low-profile floor designed to extend beneath aggregate conveyor systems. The 60-inch floor provides the reach needed to retrieve spilled or accumulated material, while the 6-inch-tall side plates allow access beneath conveyors where taller bucket sides could interfere.

The bucket has a 36-inch inside width for working in restricted cleanout areas. A 19-inch-high back helps retain collected material during removal. This combination of a narrow working width, low sides, long floor, and higher rear panel gives operators a practical profile for reaching, gathering, and carrying material away from conveyor installations.

Heavy-Duty Construction

Durability is supported by 1/4-inch-thick bucket material and matching 1/4-inch side plates. The reinforced top lip adds strength to the bucket structure, while the 3/4 x 6-inch beveled cutting edge provides a robust leading edge for engaging accumulated aggregate. The bucket is also drilled to accept a standard bolt-on cutting edge, allowing it to be equipped accordingly.

The approximate bucket weight is 525 lb in the manufacturer’s base-model configuration, measured less attachment or mounting. This reflects the bucket structure itself and does not include the weight of a machine-specific mounting arrangement.

Key Features

• Purpose-built heavy-duty bucket for cleanout beneath aggregate conveyors
• 36-inch inside width for access to confined working areas
• Long 60-inch floor provides extended reach beneath conveyor equipment
• Low 6-inch side plates help the bucket fit beneath aggregate conveyors
• 19-inch-high back assists with material retention
• 1/4-inch bucket material for heavy-duty construction
• 1/4-inch-thick side plates
• 3/4 x 6-inch beveled cutting edge
• Reinforced top lip for added structural strength
• Drilled for a standard bolt-on cutting edge
• Approximate weight of 525 lb, less attachment or mounting

Mounting Configuration

The HLA manufacturer base model SBLPC3660 is supplied less attachment/mounting. No hitch or machine-specific mounting interface is specified for this configuration. The appropriate mounting arrangement should therefore be confirmed separately for the intended carrier before purchase or installation.
