HLA Attachments - 84" 4-in-1 Skid Steer Bucket [LA-SBFNO84BO500]

HLA Attachments SBFNO84-BO500 84-inch 4-in-1 Skid Steer Bucket combines a versatile hydraulic clam design with heavy-duty bucket construction for skid steer material-handling applications. Its 4-in-1 configuration provides more operating flexibility than a conventional fixed bucket, while two hydraulic cylinders power the clam mechanism. With an 84-inch inside width, approximately 86-inch outside width and 17.7 cu ft SAE heaped capacity, this bucket offers substantial coverage and carrying capacity for compatible skid steer loaders equipped with auxiliary hydraulics and a skid-steer-style quick-attach carrier.

Versatile Hydraulic 4-in-1 Design

The SBFNO84 is built around a hydraulic 4-in-1 bucket configuration. Its opening clam expands the bucket’s functionality for varied material-handling work, making it a practical attachment when a standard bucket alone does not provide the required versatility. Operation is controlled by two 2-1/2 x 8-inch hydraulic cylinders.

The bucket profile measures 29 inches deep and 20 inches high. It provides 13.5 cu ft of struck capacity and 17.7 cu ft of SAE heaped capacity, supporting efficient handling of bulk materials. The 84-inch measurement is the bucket’s inside width; calculated outside width is approximately 86 inches.

Heavy-Duty Bucket Construction

HLA Attachments uses substantial material thicknesses throughout key areas of this bucket. The main bucket is made from 1/4-inch material, while the end plates and clam-floor bottom are each 3/8 inch thick. This construction supports demanding skid steer use and reinforces areas exposed to material loading and ground contact.

The bucket is also drilled to accept a standard bolt-on cutting edge. A cutting edge is not otherwise specified, but the factory-drilled provision allows the appropriate standard bolt-on edge to be fitted when required.

Key Features

• Hydraulic 4-in-1 skid steer bucket configuration
• 84-inch inside working width
• Approximately 86-inch calculated outside width
• 13.5 cu ft struck capacity
• 17.7 cu ft SAE heaped capacity
• Two 2-1/2 x 8-inch hydraulic cylinders
• 1/4-inch main bucket material
• 3/8-inch end plates
• 3/8-inch clam-floor bottom
• 29-inch-deep and 20-inch-high skid steer bucket profile
• Drilled for a standard bolt-on cutting edge
• BO500 skid-steer-style quick-attach mounting

Compatibility

This model is configured with HLA mounting code BO500, representing a skid-steer-style quick-attach carrier. It is intended for skid steer loaders equipped with the corresponding skid-steer-style quick-attach interface. Confirm the loader’s carrier type, hydraulic capability, attachment operating capacity and dimensional suitability before purchase or installation.

Hydraulic Requirements

Auxiliary hydraulics are required to operate the bucket’s two 2-1/2 x 8-inch cylinders. Required hydraulic flow and pressure are not specified, and hoses and couplers are not specified as included. HLA lists an optional HK90 90-inch hose kit with flat-faced couplers.

Specifications

The published 1,141 lb figure is the approximate base-bucket weight; a separate installed weight for the BO500 mounting variant is not specified.
