HLA Attachments - Universal Tilt Attachment - Skid Steer and Tractor Adapter [LA-TAUN]

HLA Attachments TAUN Universal Skidsteer Tilt Attachment is a hydraulic adapter designed to add side-to-side tilt between a skid steer and a bucket or attachment using universal skid-steer hitch interfaces. With 18° of hydraulic movement to the left and 18° to the right, it allows the operator to change the working angle of the connected attachment without repositioning the entire machine. This makes the TAUN especially useful for landscaping, grading, contouring, and other applications where controlled angle adjustments can improve accuracy and productivity.

Hydraulic Tilt for Grading and Landscaping

The TAUN installs between the skid steer and a universally mounted bucket or attachment. Once connected to hydraulic power, the adapter provides controlled tilt in either direction. Operators can adjust the attachment angle to follow changing ground contours, shape grades, work along slopes, or complete other tasks where a fixed attachment angle may be limiting.

Its bidirectional tilt range provides up to 18° of movement to the left and 18° to the right. Because the tilt function is built into the adapter, compatible buckets and attachments can gain side-to-side movement without requiring a dedicated tilting version of each attachment.

Universal Skid-Steer Hitch Interface

The HLA TAUN uses a universal skid-steer hitch on both the machine side and the attachment side. It is intended to mount to a skid steer equipped with a universal skid-steer hitch and then connect to a bucket or other attachment using the same universal interface.

The adapter has a manufacturer-rated capacity of 5,500 lb and weighs approximately 425 lb (193 kg). Its substantial capacity supports demanding attachment applications while maintaining the flexibility of a universal mounting arrangement.

Key Features

• Hydraulic universal skid-steer tilt attachment and adapter
• Mounts between the skid steer and the connected bucket or attachment
• Universal skid-steer hitch interface on both sides
• Provides 18° of hydraulic tilt to the left
• Provides 18° of hydraulic tilt to the right
• 5,500 lb manufacturer-rated capacity
• Approximately 425 lb (193 kg) attachment weight
• Designed for landscaping and grade-changing applications
• Allows attachment-angle adjustment without repositioning the complete machine

Compatibility

The TAUN is compatible with skid steers equipped with a universal skid-steer hitch. The bucket or attachment connected to the front of the tilt adapter must also be equipped with a universal skid-steer hitch interface.

• Machine connection: Universal skid-steer hitch
• Attachment connection: Universal skid-steer hitch
• Compatible machines: Skid steers with a universal skid-steer hitch
• Compatible attachments: Buckets or attachments with a universal skid-steer hitch

Hydraulic Requirements

Hydraulic power is required to operate the left-and-right tilt function. The hydraulic system supplies the movement needed to adjust the connected bucket or attachment through its 18° tilt range in either direction.

Specifications
