HLA Attachments - Three Point Hitch Skid Steer PTO Adapter Regular Flow - Skid Steer and Tractor Adapter [LA-PTORF]

HLA Attachments PTORF Three Point Hitch Skid Steer PTO Adapter converts regular-flow skid-steer hydraulic power into a hydraulic PTO while adding a Category 1 and Category 2 compatible three-point hitch. Designed for hydraulically powered PTO implements such as brush cutters and snow blowers, this adapter delivers a 20–25 HP PTO power output when supplied with 20–25 GPM hydraulic flow. Its 4,000 lb three-point capacity, adjustable top link, included hydraulic hose and coupler kit, and integrated 2-inch receiver provide a versatile connection point for a range of implements and attachments.

Hydraulic PTO and Three-Point Capability

The PTORF provides skid steers with both hydraulic PTO power and a three-point implement connection. This allows a compatible skid steer to operate hydraulically powered PTO implements while supporting Category 1 or Category 2 three-point mounting. It is the regular-flow version of HLA Attachments’ skid-steer PTO adapter and is rated for hydraulic systems delivering between 20 and 25 GPM.

A PTO power output range of 20–25 HP makes the adapter suitable for compatible applications such as brush cutting and snow removal. The three-point hitch is rated for a capacity of 4,000 lb, providing a substantial mounting platform for compatible implements. An adjustable top link is included to support implement positioning and hitch adjustment.

Ready for Hydraulic Connection

HLA Attachments includes a hose and coupler kit with the PTORF, providing the required connection components for the adapter’s hydraulic system. The integrated 2-inch receiver adds another useful attachment point, further expanding the adapter’s versatility around the property, farm, or worksite.

Key Features

• Adds a hydraulic PTO and three-point hitch to a compatible skid steer
• Regular-flow design requiring 20–25 GPM
• Provides 20–25 HP PTO power output
• Compatible with Category 1 and Category 2 three-point implements
• 4,000 lb three-point capacity
• Adjustable top link included
• Hose and coupler kit included
• Integrated 2-inch receiver
• Approximate adapter weight of 440 lb

Compatibility

The HLA Attachments PTORF is designed for use with skid steers equipped with regular-flow hydraulics in the specified flow range. Its three-point hitch accommodates both Category 1 and Category 2 implements. It can be used with compatible hydraulically powered PTO implements, including brush cutters and snow blowers, provided the implement is suitable for the adapter’s PTO power output and three-point configuration.

Hydraulic Requirements

This regular-flow PTO adapter requires a hydraulic flow of 20–25 GPM. Within this rated flow range, it provides a 20–25 HP PTO power output. Confirm that the skid steer’s hydraulic system and the intended implement match these requirements before use.

Specifications
